System And Components
355-9984 LINES GP-TURBOCHARGER OILS/N FHS1-UP
Group No: 355-9984
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P1230 | 1 CONNECTOR | 1 | |
| 9M2564 | 2 CLAMP-TUBE | 8 | |
| 9U6993 | 3 ADAPTER AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 0694269 | ADAPTER | 1 | |
| 1978418 | 4 GASKET | 2 | |
| 3498519 | 5 ELBOW AS | 1 | |
| 6V9003 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3563757 | 6 TUBE AS | 1 | |
| 3563760 | 7 TUBE AS | 1 | |
| 3563761 | 8 TUBE AS | 1 | |
| 3578317 | 9 TUBE AS | 1 | |
| 0S1594 | 10 BOLT (3/8-16X1-IN) | 4 | |
| 1978419 | 11 GASKET | 2 | |
| 1B2790 | 12 BOLT (5/16-18X1.375-IN) | 4 | |
| 2385082 | 13 SEAL-O-RING | 1 | |
| 2815977 | 14 CONNECTOR AS | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 4B3388 | 15 BOLT (5/16-18X1.125-IN) | 4 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 7X7958 | 17 CLAMP-HOSE | 4 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9S8752 | 19 NUT-FULL (3/8-16-THD) | 4 | |
| 4477466 | 20 HOSE | 2 |
