System And Components
348-2222 DRIVE GP-FANS/N ZRS1-UP
Group No: 348-2222
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N0598 | 1 PULLEY-FAN DRIVE (4-GROOVE) | 1 | |
| 6N2538 | 2 BRACKET-FAN ADJUSTMENT | 1 | |
| 6N2547 | 3 ADAPTER-FAN BRACKET | 1 | |
| 7E4808 | 4 PLATE | 1 | |
| 1809571 | 5 V-BELT SET (INCLUDES 4-BELTS)(INCLUDES 4-BELTS, FAN DRIVE) | 1 | |
| 4446555 | 6 BRACKET AS | 1 | |
| 4N0684 | DOWEL | 1 | |
| 3330773 | 7 SPACER-SPECIAL (39X47.5X18-MM THK) | 1 | |
| 3330774 | 8 HUB | 1 | |
| 3330776 | 9 SPACER-SPECIAL | 1 | |
| 3330777 | 10 ADAPTER | 1 | |
| 3332408 | 11 BALL BEARING | 2 | |
| 3623608 | 12 ADAPTER | 1 | |
| 0S1585 | 13 BOLT (1/2-13X1.5-IN) | 2 | |
| 1A2029 | 14 BOLT (3/8-16X1.125-IN) | 2 | |
| 2M2488 | 15 STUD-TAPERLOCK (3/8-16X3.59-IN) | 6 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 5P8245 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6H3956 | 18 PIN | 1 | |
| 6V8801 | 19 NUT (3/8-16-THD) | 1 | |
| 7D1649 | 20 WASHER-HARD (13.5X32X5-MM THK) | 4 | |
| 5R1771 | 21 BOLT (3/8-16X5.5-IN) | 1 | |
| 9S8752 | 22 NUT-FULL (3/8-16-THD) | 6 | |
| 9X8874 | 23 BOLT (1/2-13X3-IN) | 1 | |
| 9X8877 | 24 BOLT (1/2-13X5-IN) | 2 | |
| 2D8155 | 25 STUD-TAPERLOCK (1/2-13X3.58-IN) | 4 | |
| 1F7958 | 26 NUT-FULL (1/2-13-THD) | 4 | |
| 4206942 | 27 SPACER (40.4X49X5-MM THK) | 1 |
