System And Components
509-6099 AIR CLEANER GPS/N LNB1-UP
Group No: 509-6099
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I2933 | 1 INDICATOR-AIR FILTER SERVICE | 1 | |
| 8T4988 | 2 CLAMP-HOSE | 3 | |
| 9X6654 | 3 CLAMP-HOSE | 3 | |
| 1131584 | 4 STRIP | 2 | |
| 2022173 | 5 HOSE | 1 | |
| 2410566 | 6 HOSE | 1 | |
| 2416592 | 7 TUBE | 1 | |
| 2435381 | 8 HOSE | 1 | |
| 2435605 | 9 HOSE | 1 | |
| 2436499 | 10 TUBE | 1 | |
| 2465010 | 11 FILTER ELEMENT AS-AIR (SECONDARY) | 1 | |
| 2544293 | 12 CAP GP-AIR CLEANER | 1 | |
| 5P0600 | CLAMP-HOSE | 1 | |
| 3764660 | 13 AIR CLEANER GP | 1 | |
| 3880334 | 14 BRACKET AS | 1 | |
| 3908436 | 15 STRAP | 1 | |
| 4170634 | 16 BRACKET | 1 | |
| 4253590 | 17 BRACKET | 1 | |
| 1007749 | 18 U-BOLT | 2 | |
| 1757141 | 19 NUT-HEX FLANGE (M10X1.5-THD) | 2 | |
| 3383669 | 20 BOLT-FLANGE HEAD (M10X1.5X30-MM) | 2 | |
| 5S7379 | 21 BOLT (3/8-16X0.875-IN) | 2 | |
| 6V8801 | 22 NUT (3/8-16-THD) | 4 | |
| 7X0366 | 23 BOLT (3/4-10X2-IN) | 2 | |
| 7X0582 | 24 WASHER-HARD (20X44.5X6-MM THK) | 2 | |
| 8T4896 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 8T4990 | 26 CLAMP-HOSE | 2 | |
| 8T7008 | 27 BOLT (3/8-16X3-IN) | 4 |
