376-9205 HOOD GP-TRUCKS/N KEG1-UP

Group No: 376-9205
Part NumberPart NameQty
2T17181 RETAINER2
8C64132 SPRING AS-GAS (HOOD)1
8H53053 WASHER (0.266X0.5X0.105-IN THK)2
9D79244 MOUNTING AS4
9D83885 HINGE-HOOD1
9M27606 ANCHOR2
11934507 SPACER (13.5X30X30-MM THK)4
11997068 STUD-BALL2
23501609 BRACKET AS1
239729010 SUPPORT AS1
252569911 PLUG-PROTECTION1
275057212 LATCH AS1
340457013 SUPPORT AS1
9F6445NUT-WELD (1/4-20-THD)4
340457214 SUPPORT AS1
366604515 HOOD AS1
4D2328BLOCK2
9V7451NUT-WELD (1/4-20-THD)4
366604716 HOOD GP-TRUCK1
379522617 DOOR AS-ACCESS1
2619500HINGE AS1
379522718 CAM-LOCK1
2K497319 LOCKNUT (3/8-16-THD)4
2M579520 PIN-CLEVIS2
3B460721 PIN-COTTER2
5P107522 WASHER-HARD (10.2X22.5X3-MM THK)12
5P107623 WASHER-HARD (13.5X30X4-MM THK)4
5S734924 BOLT (1/4-20X0.5-IN)6
5S737925 BOLT (3/8-16X0.875-IN)18
5S738226 BOLT (3/8-16X1.375-IN)4
8T256127 WASHER-HARD (10.5X28.5X5-MM THK)12
8T412128 WASHER-HARD (11X21X2.5-MM THK)2
8T413329 NUT (M10X1.5-THD)1
8T420530 WASHER-HARD (7.2X14.5X2-MM THK)6
8T422631 WASHER-PLATED (10.5X45X3-MM THK)8
8T489632 WASHER-HARD (10.2X18.5X2.5-MM THK)6
8T937733 BOLT (3/8-16X2.25-IN)4
8T938934 BOLT (1/2-13X2.75-IN)4
9M383535 LATCH-RUBBER2
