System And Components
432-3032 FAN GP-BLOWERS/N MH41-UP; MT41-UP
Group No: 432-3032
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1837170 | 1 VALVE GP-MAKEUP (HYDRAULIC FAN MOTOR) | 1 | |
| 1860131 | 2 SENSOR GP-SPEED (FAN) | 1 | |
| 2573471 | 3 ADAPTER | 1 | |
| 3035859 | 4 MOTOR GP-PISTON (BLOWER FAN) | 1 | |
| 4323731 | 5 HOSE AS | 1 | |
| 4323739 | 6 HOSE AS | 2 | |
| 4329691 | 7 BLOWER AS | 1 | |
| 5F3106 | SEAL-O-RING | 1 | |
| 8T7338 | BOLT (M16X2X45-MM) | 6 | |
| 1615849 | KEY | 1 | |
| 1984780 | WASHER-HARD (17.5X32X8-MM THK) | 6 | |
| 4658103 | BEARING AS | 1 | |
| 4520437 | 8 ELBOW AS | 2 | |
| 2287092 | SEAL-O-RING | 1 | |
| 4345384 | ELBOW | 1 | |
| 4520441 | 9 ADAPTER AS | 2 | |
| 2287093 | SEAL-O-RING | 1 | |
| 4429593 | ADAPTER-STRAIGHT | 1 | |
| 1244287 | 10 FLANGE-SPLIT | 4 | |
| 1313025 | 11 FLANGE-SPLIT | 4 | |
| 2815972 | 12 CONNECTOR AS | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 4520434 | 13 TEE AS | 1 | |
| 6V9846 | TEE | 2 | |
| 2287092 | SEAL-O-RING | 1 | |
| 1093205 | 14 SEAL-O-RING | 2 | |
| 1907673 | 15 SEAL-O-RING | 2 | |
| 2385082 | 17 SEAL-O-RING | 1 | |
| 4520435 | 18 ADAPTER AS | 1 | |
| 3E7420 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 4L9337 | 19 BOLT (3/8-16X1.5-IN) | 8 | |
| 6V7673 | 20 BOLT (M12X1.75X50-MM) | 8 | |
| 4520436 | 21 REDUCER AS | 2 | |
| 6V8946 | REDUCER | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 7X0343 | 22 BOLT (5/8-11X1.25-IN) | 8 | |
| 7X0515 | 23 WASHER-HARD (17X35X5-MM THK) | 8 | |
| 8T4192 | 24 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4194 | 25 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4223 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 15 | |
| 8T4896 | 27 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 2287103 | 28 SEAL-O-RING | 1 | |
| 8T4179 | 29 BOLT (M12X1.75X20-MM) | 1 | |
| 6V4349 | 30 GROMMET | 1 | |
| 5P7469 | 31 CLIP (TAB) | 1 | |
| 5P7468 | 32 CLIP (SLOT) | 1 |
