System And Components
461-7558 LINES GP-HOISTS/N MN51-UP; MT51-120
Group No: 461-7558
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C9762 | 1 MANIFOLD | 1 | |
| 5P4272 | 2 UNION | 1 | |
| 2147568 | 3 SEAL-O-RING | 2 | |
| 2260835 | 4 VALVE GP-PRESSURE REDUCING (HOIST PILOT OIL) | 1 | |
| 2471437 | 5 VALVE GP-CONTROL (BRAKE COOLING, HOIST) | 1 | |
| 2638522 | 6 SPACER | 2 | |
| 3196248 | 7 UNION AS | 4 | |
| 5P9560 | UNION | 1 | |
| 2385082 | SEAL-O-RING | 2 | |
| 4327469 | 8 CLAMP AS | 9 | |
| 5S7383 | BOLT (3/8-16X1.75-IN) | 2 | |
| 4345618 | NUT-SPECIAL | 2 | |
| 4329410 | 9 CLAMP AS | 4 | |
| 7X0318 | BOLT (7/16-14X4-IN) | 2 | |
| 4538940 | INSERT-NUT | 2 | |
| 4329905 | 10 CLAMP AS | 2 | |
| 5S7383 | BOLT (3/8-16X1.75-IN) | 2 | |
| 4345618 | NUT-SPECIAL | 2 | |
| 4423390 | 11 BRACKET AS | 1 | |
| 4423395 | 12 BLOCK GP-HYDRAULIC (ADAPTER) | 1 | |
| 8B7997 | BOLT-SOCKET HEAD (1/2-13X2-IN) | 4 | |
| 8T0568 | SEAL-O-RING | 1 | |
| 4423394 | BLOCK-ADAPTER | 1 | |
| 4423402 | 13 HOSE AS | 2 | |
| 4423505 | 14 FLANGE & MOUNTING GP | 1 | |
| 4423506 | 15 FLANGE & MOUNTING GP | 2 | |
| 4532601 | 16 ADAPTER AS | 2 | |
| 2287094 | SEAL-O-RING | 1 | |
| 4345383 | ELBOW | 1 | |
| 4617560 | 17 HOSE AS | 1 | |
| 4617561 | 18 HOSE AS | 1 | |
| 4635810 | 19 BRACKET AS | 1 | |
| 4635813 | 20 TUBE AS | 1 | |
| 4635814 | 21 TUBE AS | 1 | |
| 4635815 | 22 TUBE AS | 1 | |
| 4635816 | 23 TUBE AS | 1 | |
| 4635867 | 24 HOSE AS | 1 | |
| 4725725 | 25 HOSE AS | 2 | |
| 4727058 | 26 FILTER AS-OIL (BRAKE COOLING, HOIST) | 2 | |
| 4176162 | FILTER-OIL | 1 | |
| 4538935 | COVER AS-FILTER (CARTRIDGE, OIL) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3603692 | PLUG (9/16-18-THD) | 1 | |
| 4784756 | 27 FLANGE-SPACER | 2 | |
| 4934313 | 28 BRACKET AS | 1 | |
| 4934314 | 29 BRACKET AS | 1 | |
| 1313025 | 30 FLANGE-SPLIT | 4 | |
| 1833399 | 31 CONNECTOR AS | 3 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1907673 | 32 SEAL-O-RING | 2 | |
| 1912962 | 33 SEAL-O-RING | 8 | |
| 1B8471 | 34 CLIP | 1 | |
| 1P4578 | 35 FLANGE-HALF | 4 | |
| 1P4579 | 36 FLANGE-HALF | 4 | |
| 1P4582 | 37 FLANGE-HALF | 2 | |
| 2343544 | 38 SEAL-O-RING | 4 | |
| 2352476 | 39 SEAL-RECTANGULAR | 2 | |
| 2977968 | 40 FITTING | 4 | |
| 2977969 | 41 CAP-DUST | 4 | |
| 3048037 | 42 CONNECTOR AS | 2 | |
| 6V9872 | CONNECTOR | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3196240 | 43 CONNECTOR AS | 4 | |
| 6V9873 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3218613 | 44 TEE AS | 1 | |
| 6V9161 | TEE | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 2 | |
| 3218649 | 45 VALVE AS-FLUID SAMPLING | 1 | |
| 8C3446 | VALVE-SAMPLING | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3309735 | 46 ELBOW AS | 4 | |
| 8T3491 | ELBOW | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3D8908 | 47 COVER | 1 | |
| 6C3241 | 48 BOLT (1/2-13X1.5-IN) | 3 | |
| 6V4432 | 49 BOLT (1/2-13X4-IN) | 8 | |
| 6V4590 | 50 SEAL-O-RING | 2 | |
| 6V8188 | 51 NUT (1/2-13-THD) | 3 | |
| 7X0315 | 52 BOLT (7/16-14X3.25-IN) | 8 | |
| 7X2553 | 53 BOLT (M16X2X40-MM) | 5 | |
| 8C3451 | 54 CAP-DUST (HYDRAULIC OIL) | 1 | |
| 8C8451 | 55 BOLT (M6X1X40-MM) | 2 | |
| 8T4121 | 56 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4139 | 57 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4176 | 58 BOLT (M12X1.75X90-MM) | 4 | |
| 8T4192 | 59 BOLT (M12X1.75X25-MM) | 8 | |
| 8T4194 | 60 BOLT (M12X1.75X50-MM) | 8 | |
| 8T4195 | 61 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 62 WASHER-HARD (13.5X25.5X3-MM THK) | 36 | |
| 8T4224 | 63 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4648 | 64 BOLT (M12X1.75X70-MM) | 8 | |
| 8T5360 | 65 WASHER (12X22.5X2.5-MM THK) | 8 | |
| 8T6870 | 66 BOLT (M8X1.25X70-MM) | 2 | |
| 8T8919 | 67 BOLT (1/2-13X1.75-IN) | 4 | |
| 9X8256 | 68 WASHER (6.6X12X2-MM THK) | 2 | |
| 9X8257 | 69 WASHER (17.5X30X3.5-MM THK) | 5 | |
| 4652347 | 70 HOSE AS | 2 |
