System And Components
461-6650 LINES GP-HYDRAULIC FANS/N MN51-UP; MT51-UP
Group No: 461-6650
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1106349 | 1 FITTING AS (QUICK DISCONNECT) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1244288 | 2 FLANGE-SPLIT | 4 | |
| 1313025 | 3 FLANGE-SPLIT | 2 | |
| 1566129 | 4 ADAPTER | 2 | |
| 1645567 | 5 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1705715 | 6 SEAL-O-RING | 2 | |
| 1837170 | 7 VALVE GP-MAKEUP | 1 | |
| 1912962 | 8 SEAL-O-RING | 1 | |
| 1P4579 | 9 FLANGE-HALF | 2 | |
| 1P5767 | 10 FLANGE-HALF | 6 | |
| 2067013 | 11 FASTENER | 4 | |
| 2159209 | 12 HOSE AS | 1 | |
| 2287088 | 13 SEAL-O-RING | 1 | |
| 2287090 | 14 SEAL-O-RING | 2 | |
| 2343544 | 15 SEAL-O-RING | 2 | |
| 2352475 | 16 SEAL-RECTANGULAR | 3 | |
| 2413974 | 17 VALVE GP-CHECK | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 2815972 | 18 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2880267 | 19 ELBOW | 1 | |
| 3035861 | 20 MOTOR GP-PISTON (BLOWER FAN) | 1 | |
| 3156643 | 21 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3196226 | 22 ELBOW AS | 1 | |
| 8T6876 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3196231 | 23 PLUG AS | 2 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3295534 | 24 CONNECTOR AS | 1 | |
| 8C5723 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3309754 | 25 CONNECTOR AS | 1 | |
| 8T3611 | CONNECTOR | 1 | |
| 2287094 | SEAL-O-RING | 1 | |
| 2287096 | SEAL-O-RING | 1 | |
| 3328592 | 26 ELBOW AS | 1 | |
| 1523411 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3696823 | 27 ELBOW AS | 2 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 3696822 | ADAPTER-ELBOW | 1 | |
| 3B8489 | 28 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 4205299 | 29 CLIP (LOOP) | 2 | |
| 4310657 | 30 HOSE AS | 1 | |
| 4350693 | 31 PLATE-COVER | 2 | |
| 5P4116 | 32 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 4357441 | 33 PLATE-COVER | 3 | |
| 4520434 | 34 TEE AS | 1 | |
| 6V9846 | TEE | 1 | |
| 2287092 | SEAL-O-RING | 2 | |
| 4520435 | 35 ADAPTER AS | 1 | |
| 3E7420 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 4580448 | 36 VALVE GP-SOLENOID & MANIFOLD | 1 | |
| 4616651 | 37 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 4616657 | 38 HOSE AS | 1 | |
| 4616658 | 39 HOSE AS | 1 | |
| 4616660 | 40 HOSE AS | 1 | |
| 4616661 | 41 HOSE AS | 1 | |
| 4647038 | 42 HOSE AS | 2 | |
| 4689673 | 43 CLAMP-HALF | 6 | |
| 4883971 | 44 BOLT AS | 1 | |
| 4936342 | 45 CLAMP-HALF | 4 | |
| 4M6425 | 46 BOLT (5/16-18X1-IN) | 1 | |
| 5031358 | 47 NUT (M12X1-THD) | 4 | |
| 5847447 | 48 ADAPTER AS | 1 | |
| 2385078 | SEAL-O-RING | 1 | |
| 5851251 | ADAPTER | 1 | |
| 5901455 | 49 HOSE AS | 1 | |
| 5901456 | 50 HOSE AS | 1 | |
| 5P1076 | 51 WASHER-HARD (13.5X30X4-MM THK) | 3 | |
| 6C3241 | 52 BOLT (1/2-13X1.5-IN) | 4 | |
| 5P7468 | 53 CLIP (SLOT) | 2 | |
| 5P7469 | 54 CLIP (TAB) | 2 | |
| 5U7151 | 55 CAP-GREASE | 2 | |
| 6V0852 | 56 CAP-DUST | 2 | |
| 6V4349 | 57 GROMMET | 2 | |
| 6V9169 | 58 NUT (13/16-16-THD) | 2 | |
| 7X2545 | 59 BOLT (M10X1.5X150-MM) | 4 | |
| 7X2549 | 60 BOLT (M12X1.75X100-MM) | 4 | |
| 8T4121 | 61 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4139 | 62 BOLT (M12X1.75X30-MM) | 6 | |
| 8T4140 | 63 BOLT (M16X2X60-MM) | 2 | |
| 8T4183 | 64 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4194 | 65 BOLT (M12X1.75X50-MM) | 16 | |
| 8T4223 | 66 WASHER-HARD (13.5X25.5X3-MM THK) | 35 | |
| 8T6466 | 67 BOLT (M10X1.5X60-MM) | 6 | |
| 9X8257 | 68 WASHER (17.5X30X3.5-MM THK) | 2 |
