385-2612 AFTERCOOLER GP-AIRS/N TFB1-UP
Group No: 385-2612 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3442576 | 1 CABLE AS | 1 | |
| 3710869 | 2 CORE AS-AFTERCOOLER | 1 | |
| 3710870 | 3 CORE AS-CONDENSER | 1 | |
| 3178141 | MOUNT | 4 | |
| 3710871 | 4 CORE AS-FUEL COOLER | 1 | |
| 3178141 | MOUNT | 4 | |
| 3852614 | 5 HINGE AS (LEFT) | 1 | |
| 4483373 | 6 HINGE AS (RIGHT) | 1 | |
| 1135522 | 7 SPACER AS | 2 | |
| 2089281 | 8 BOLT-FLANGE HEAD (M8X1.25X20-MM) | 2 | |
| 3T0852 | 9 LOCKNUT (M8X1.25-THD) | 8 | |
| 7X0579 | 10 WASHER-HARD (8.8X25.5X2-MM THK) | 8 | |
| 7X0613 | 11 WASHER-HARD (8.8X25.5X5-MM THK) | 6 | |
| 8T4908 | 12 BOLT (M8X1.25X25-MM) | 6 |
