System And Components
456-2281 BRACKET GP-MOUNTING -RHS/N TFB1-UP
Group No: 456-2281 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3684100 | 1 SHEET-RUBBER | 1 | |
| 3685853 | 2 BAR-BRACKET | 1 | |
| 3697329 | 3 SWIVEL AS | 1 | |
| 4403076 | 4 BRACKET AS | 1 | |
| 4403078 | 5 BRACKET AS | 1 | |
| 5P1076 | 6 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 6V3822 | 7 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4121 | 8 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4131 | 9 NUT (M20X2.5-THD) | 2 | |
| 8T4133 | 10 NUT (M10X1.5-THD) | 2 | |
| 8T4244 | 11 NUT (M12X1.75-THD) | 1 | |
| 8T4910 | 12 BOLT (M12X1.75X60-MM) | 1 |
