435-0408 AIR CLEANER GPS/N NRC1-UP; JAZ1-UP

Group No: 435-0408
Part NumberPart NameQty
5P38601 CLAMP-HOSE6
14542112 ADAPTER AS-FILTER2
7J0204SEAL-O-RING1
15050303 INDICATOR-AIR FILTER CHANGE2
16221774 HOSE2
28715295 AIR CLEANER GP2
36267016 HOSE2
43503947 PLATE AS2
8T3490NUT-WELD (M10X1.5-THD)2
43503988 PLATE AS2
8T3490NUT-WELD (M10X1.5-THD)2
43504059 TUBE-AIR1
435040610 TUBE-AIR1
437508511 BRACKET2
437508712 BRACKET2
140502213 ADAPTER2
331597914 CLAMP-HOSE2
4M642515 BOLT (5/16-18X1-IN)10
5P107516 WASHER-HARD (10.2X22.5X3-MM THK)4
5P411617 WASHER-HARD (8.8X20.5X2-MM THK)10
6V880118 NUT (3/8-16-THD)2
7X772919 WASHER (11X25X3-MM THK)16
8T413720 BOLT (M10X1.5X20-MM)8
8T419521 BOLT (M10X1.5X30-MM)8
8T499022 CLAMP-HOSE2
9B723723 BOLT (3/8-16X1.25-IN)2
