System And Components
339-6196 LINES GP-AIRS/N NRC1-UP; JAZ1-UP
Group No: 339-6196
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1270929 | 1 CLAMP-V BAND | 2 | |
| 2177088 | 2 HOSE | 4 | |
| 2178947 | 3 ELBOW | 2 | |
| 3375340 | 4 HOSE | 4 | |
| 3376926 | 5 TUBE | 1 | |
| 3376927 | 6 TUBE | 1 | |
| 3376929 | 7 TUBE | 1 | |
| 3376930 | 8 TUBE | 1 | |
| 4583027 | 9 PLATE | 2 | |
| 3381630 | 10 BRACKET | 1 | |
| 3381633 | 11 BRACKET AS | 1 | |
| 4583026 | 12 PLATE | 2 | |
| 6V5048 | 13 SEAL-O-RING | 2 | |
| 6V6782 | 14 CLIP (SLOT) | 6 | |
| 6V6783 | 15 CLIP (TAB) | 6 | |
| 7X7729 | 16 WASHER (11X25X3-MM THK) | 20 | |
| 8C3089 | 17 SEAL-O-RING | 2 | |
| 3445675 | 18 NUT (M10X1.5-THD) | 8 | |
| 8T4184 | 19 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4186 | 20 BOLT (M10X1.5X40-MM) | 8 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 3293356 | 22 NUT (M12X1.75-THD) | 4 | |
| 9S8002 | 23 PLUG (7/16-20-THD) | 2 | |
| 9X2201 | 24 CLAMP-HOSE | 16 | |
| 9X6654 | 25 CLAMP-HOSE | 16 | |
| 5P1076 | 26 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 1984777 | 27 WASHER-HARD (11X25X10-MM THK) | 2 | |
| 8T4185 | 28 BOLT (M10X1.5X50-MM) | 4 |
