System And Components
440-1622 LINES GP-AIRS/N JPE1-UP; PRH1-UP
Group No: 440-1622
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5N4436 | 1 COVER | 1 | |
| 9N1941 | 2 CLAMP-V BAND | 2 | |
| 4805118 | 3 CLAMP-BAND | 2 | |
| 2361161 | 4 ELBOW | 1 | |
| 2361637 | 5 SEAL | 2 | |
| 2775470 | 6 PLATE | 1 | |
| 3113986 | 7 BRACKET | 1 | |
| 3113987 | 8 BRACKET | 1 | |
| 4728172 | 9 TUBE AS | 1 | |
| 4728173 | 10 TUBE AS | 1 | |
| 0S1587 | 11 BOLT (1/2-13X1.75-IN) | 2 | |
| 0S1588 | 12 BOLT (3/8-16X1.25-IN) | 2 | |
| 1653929 | 13 BOLT (3/8-16X1.5-IN) | 8 | |
| 0S1594 | 14 BOLT (3/8-16X1-IN) | 4 | |
| 1F7958 | 15 NUT-FULL (1/2-13-THD) | 2 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 5N4435 | 17 GASKET | 1 | |
| 5P8245 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6V1820 | 19 BOLT (M10X1.5X30-MM) | 8 | |
| 6V5839 | 20 WASHER (11X21X2.5-MM THK) | 8 | |
| 7W2033 | 21 CLIP (TAB) | 2 | |
| 7W2034 | 22 CLIP (SLOT) | 2 | |
| 9S8752 | 23 NUT-FULL (3/8-16-THD) | 10 |
