System And Components
Assembly
100%

448-4295 LINES GP-AIRS/N NRC1-UP; JAZ1-UP

Group No: 448-4295
Part NumberPart NameQty
7W31451 PLATE4
19290062 ELBOW2
21770883 HOSE4
33753404 HOSE4
33769265 TUBE1
33769276 TUBE1
45830277 PLATE2
33816308 BRACKET1
33816339 BRACKET AS1
458302610 PLATE2
449023511 TUBE1
449023612 TUBE1
0S159413 BOLT (3/8-16X1-IN)4
198477714 WASHER-HARD (11X25X10-MM THK)2
329335615 NUT (M12X1.75-THD)4
344567516 NUT (M10X1.5-THD)8
5H770417 SEAL-O-RING4
5M289418 WASHER-HARD (10.2X18.5X2.5-MM THK)4
5P107619 WASHER-HARD (13.5X30X4-MM THK)4
6V678220 CLIP (SLOT)6
6V678321 CLIP (TAB)6
7X772922 WASHER (11X25X3-MM THK)20
8T418423 BOLT (M12X1.75X45-MM)4
8T418524 BOLT (M10X1.5X50-MM)4
8T418625 BOLT (M10X1.5X40-MM)8
8T422326 WASHER-HARD (13.5X25.5X3-MM THK)4
8T675727 PLUG-PIPE2
9X220128 CLAMP-HOSE16
9X665429 CLAMP-HOSE16
