System And Components
473-7816 SHIELD GP-EXHAUSTS/N JAZ1-UP
Group No: 473-7816
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1640150 | 1 SPACER (9X20X20-MM THK) | 2 | |
| 4623273 | 2 BRACKET | 4 | |
| 4623274 | 3 BRACKET | 2 | |
| 4737817 | 4 SHIELD AS-EXHAUST | 2 | |
| 7K6536 | RIVET-POP | 4 | |
| 2495156 | PLATE-WARNING (HOT SURFACE, HANDS CLEAR) | 1 | |
| 4737819 | 5 PLATE | 1 | |
| 4737820 | 6 PLATE | 1 | |
| 1984776 | 7 WASHER-HARD (8.8X20X8-MM THK) | 18 | |
| 3445674 | 8 NUT (M8X1.25-THD) | 12 | |
| 5D3635 | 9 NUT (5/16X18-THD) | 2 | |
| 5P4116 | 10 WASHER-HARD (8.8X20.5X2-MM THK) | 12 | |
| 8T4224 | 11 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4908 | 12 BOLT (M8X1.25X25-MM) | 8 | |
| 8T7547 | 13 BOLT (M8X1.25X30-MM) | 10 |
