System And Components
457-8489 SHIELD GP-TURBOCHARGERS/N JAZ1-UP
Group No: 457-8489
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2839828 | 1 SHIELD AS-TURBOCHARGER (TURBOCHARGER OUTLET, RH) | 1 | |
| 2839829 | 2 SHIELD AS-TURBOCHARGER (TURBOCHARGER OUTLET, LH) | 1 | |
| 2839830 | 3 SHIELD AS-HEAT | 1 | |
| 2839831 | 4 SHIELD AS-ELBOW | 1 | |
| 4578488 | 5 SHIELD AS | 2 | |
| 7K6536 | RIVET-POP | 4 | |
| 2495156 | PLATE-WARNING (HOT SURFACE, HANDS CLEAR) | 1 | |
| 4580866 | 6 PLATE | 1 | |
| 4580867 | 7 PLATE | 1 | |
| 4623273 | 8 BRACKET | 4 | |
| 4623274 | 9 BRACKET | 2 | |
| 4627074 | 10 CLAMP | 2 | |
| 1984776 | 11 WASHER-HARD (8.8X20X8-MM THK) | 18 | |
| 3445674 | 12 NUT (M8X1.25-THD) | 12 | |
| 5P4116 | 13 WASHER-HARD (8.8X20.5X2-MM THK) | 12 | |
| 6V8189 | 14 NUT (5/16-18-THD) | 2 | |
| 8T7547 | 15 BOLT (M8X1.25X30-MM) | 10 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4908 | 17 BOLT (M8X1.25X25-MM) | 8 |
