System And Components
384-4678 MUFFLER & MOUNTING GPS/N LC41-UP
Group No: 384-4678
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4195 | 1 BOLT (M10X1.5X30-MM) | 16 | |
| 3887008 | 2 CLAMP-BENT BOLT | 2 | |
| 3539725 | 3 MUFFLER AS | 1 | |
| 5M6213 | PLUG-PIPE (1/4-18-THD) | 1 | |
| 3539727 | 4 TUBE | 1 | |
| 3539782 | 5 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3377304 | 6 CLAMP-BAND | 1 | |
| 3844679 | 7 BELLOWS | 1 | |
| 3844680 | 8 TUBE AS | 1 | |
| 4393519 | 9 SHROUD AS | 1 | |
| 7S4995 | 10 CAP AS-RAIN (EXHAUST) | 1 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 18 | |
| 8T4133 | 12 NUT (M10X1.5-THD) | 2 | |
| 2460992 | TAPE (INSULATION) |
