System And Components
483-7000 TURBOCHARGER GPS/N E3L1-UP; E3N1-UP
Group No: 483-7000
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0217 | 1 BOLT (M8X1.25X20-MM) | 2 | |
| 6I0260 | 2 BOLT (M8X1.25X25-MM) | 2 | |
| 6I0563 | 3 NUT (M10X1.5-THD) | 7 | |
| 6I0572 | 4 BOLT (M8X1.25X20-MM) | 4 | |
| 6I0593 | 5 BOLT (M10X1.5X30-MM) | 2 | |
| 6I0654 | 6 BOLT (M10X1.5X25-MM) | 3 | |
| 1004830 | 7 BOLT (M10X1.5X20-MM) | 4 | |
| 1017856 | 8 CAP (AIR CLEANER) | 1 | |
| 1036714 | 9 CLIP | 1 | |
| 1068916 | 10 BOLT (M6X1X16-MM) | 2 | |
| 1102556 | 11 AIR CLEANER GP | 1 | |
| 1106326 | 11A FILTER ELEMENT AS-AIR (PRIMARY) | 1 | |
| 1106331 | 11B FILTER ELEMENT AS-AIR (SECONDARY) | 1 | |
| 1749638 | 12 BOLT (M10X1.5X30-MM) | 8 | |
| 1945390 | 13 GASKET-MANIFOLD | 1 | |
| 2258525 | 14 TUBE AS | 1 | |
| 2258524 | 14A BOLT-SPECIAL (M10X1.5X23-MM) | 2 | |
| 2258526 | 14B WASHER (10.4X13.75X1.37-MM THK) | 4 | |
| 2258530 | 15 GASKET | 1 | |
| 2258536 | 16 GASKET | 1 | |
| 2274562 | 17 ELBOW-EXHAUST | 1 | |
| 2326189 | 18 TUBE AS | 1 | |
| 2343029 | 19 HOSE | 1 | |
| 2368750 | 20 HOSE-AIR | 1 | |
| 2667092 | 21 CLAMP-HOSE | 2 | |
| 2864339 | 22 BRACKET-MOUNTING | 1 | |
| 3020581 | 23 ADAPTER-EXHAUST | 1 | |
| 3072805 | 24 BRACKET | 1 | |
| 3154691 | 25 INDICATOR-AIR FILTER CHANGE | 1 | |
| 5586994 | 26 TURBOCHARGER AS | 1 | |
| 3533477 | 27 GASKET-TURBOCHARGER | 1 | |
| 3533478 | 28 GASKET-TURBOCHARGER | 1 | |
| 3617519 | 29 ROD-THREADED | 7 | |
| 3675799 | 30 TUBE | 1 | |
| 3712636 | 31 CLIP-HOSE | 1 | |
| 3716059 | 32 MANIFOLD-EXHAUST | 1 | |
| 4183216 | 33 BRACKET | 1 | |
| 4923310 | 34 GASKET | 1 |
