System And Components
394-3740 MUFFLER & MOUNTING GPS/N LC61-UP
Group No: 394-3740
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0619793 | 1 CLAMP-TUBE | 1 | |
| 3539680 | 2 TUBE | 1 | |
| 3539690 | 3 MUFFLER AS | 1 | |
| 5M6213 | PLUG-PIPE (1/4-18-THD) | 1 | |
| 3539695 | 4 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3377304 | 5 CLAMP-BAND | 2 | |
| 3943709 | 6 BELLOWS | 1 | |
| 3980925 | 7 TUBE AS | 1 | |
| 3980927 | 8 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3980929 | 9 BRACKET AS | 1 | |
| 3980927 | PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1987424 | 10 CAP AS-RAIN (EXHAUST) | 1 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4195 | 12 BOLT (M10X1.5X30-MM) | 16 | |
| 2460992 | TAPE (INSULATION)(100-DM) |
