System And Components
293-0607 TURBOCHARGER GPS/N E6L1-UP; E6M1-UP
Group No: 293-0607
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0217 | 1 BOLT (M8X1.25X20-MM) | 5 | |
| 6I0654 | 2 BOLT (M10X1.5X25-MM) | 4 | |
| 6I0817 | 3 ADAPTER | 1 | |
| 9Y9381 | 4 WASHER-HARD | 1 | |
| 1004830 | 5 BOLT (M10X1.5X20-MM) | 4 | |
| 2388292 | 6 BOLT-FLANGE HEAD | 12 | |
| 4374170 | 8 GASKET | 1 | |
| 2780017 | 9 GASKET | 1 | |
| 3032116 | 10 CLIP | 6 | |
| 4167727 | 12 GASKET | 2 | |
| 3154695 | 13 TURBOCHARGER | 1 | |
| 2779603 | 13A CLAMP | 1 | |
| 2779602 | 13B CLAMP | 1 | |
| 3688557 | 14 TUBE AS-TURBOCHARGER | 1 | |
| 2779938 | 14A BOLT-SPECIAL (BANJO) | 1 | |
| 3655823 | 14B WASHER | 2 | |
| 2779940 | 14C SEAL-O-RING | 1 | |
| 4202372 | 15 LINE AS (OIL DRAIN) | 1 | |
| 2802424 | 16 ADAPTER | 1 | |
| 2822830 | 17 ELBOW | 1 | |
| 2822831 | 18 TUBE AS | 1 | |
| 4B8774 | 18A NUT-FLARED | 1 | |
| 0328047 | 18B FERRULE | 1 | |
| 3006520 | 18C HOSE AS | 1 | |
| 1072348 | 18D CLIP | 2 | |
| 2947375 | 19 SOLENOID (BOOST) | 1 | |
| 2853197 | 20 TUBE AS | 1 | |
| 4B8774 | 20A NUT-FLARED | 1 | |
| 0328047 | 20B FERRULE | 2 | |
| 0358014 | 20C NUT | 1 | |
| 2860123 | 21 BOLT (M10X1.5X35-MM THK) | 3 | |
| 3154691 | 22 INDICATOR-AIR FILTER CHANGE | 1 | |
| 2867851 | 23 SPACER | 12 | |
| 3968052 | 24 MANIFOLD-EXHAUST | 1 | |
| 3440927 | 25 FILTER GP-AIR (TURBOCHARGER INLET) | 1 | |
| 1337403 | 25A VALVE-DUST | 1 | |
| 2892349 | 25B FILTER ELEMENT-AIR (SECONDARY) | 1 | |
| 2892360 | 26 CAP | 1 | |
| 2905735 | 27 BRACKET AS | 1 | |
| 2780315 | 27A CLIP-PIPE | 1 | |
| 4218534 | 28 HOSE | 1 | |
| 2685341 | 29 CLAMP-HOSE | 1 | |
| 3712636 | 30 CLIP-HOSE | 1 | |
| 2949389 | 31 BRACKET | 1 | |
| 3673340 | 32 STUD | 4 | |
| 1418589 | 33 GASKET (TURBOCHARGER) | 1 | |
| 6I0563 | 34 NUT (M10X1.5-THD) | 4 |
