System And Components
4P-4021 PUMP GP-ENGINE OILS/N 6NC1-UP; R6J1-UP; 08Z1-UP; 10Z1-UP; 13Z1-UP
Group No: 4P-4021
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W2322 | 1 BODY AS-OIL PUMP | 1 | |
| 2P1170 | 2 SHAFT AS-GEAR | 1 | |
| 4B9782 | BALL | 1 | |
| 4B9880 | 3 BALL | 1 | |
| 1F1006 | 4 DOWEL | 1 | |
| 8S6511 | 5 BUSHING | 2 | |
| 5M2894 | 6 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 4P3546 | 7 VALVE AS-RELIEF | 1 | |
| 1B9575 | 8 BOLT (5/16-18X1.56-IN) | 1 | |
| 0T0573 | 9 BOLT (3/8-16X2.75-IN) | 2 | |
| 0S1591 | 10 BOLT (3/8-16X1.5-IN) | 1 | |
| 2P0674 | 11 SHAFT AS-OIL PUMP | 1 | |
| 2P0696 | 12 SHAFT AS-OIL PUMP | 2 | |
| 7J2036 | 13 SEAL-O-RING | 1 | |
| 7W4455 | 14 COVER AS | 1 | |
| 8S6511 | 15 BUSHING | 2 |
