System And Components
1W-1604 CARTRIDGE GP-TURBOCHARGERS/N 6NC1-UP; 08Z1-UP
Group No: 1W-1604
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N0819 | 1 PLATE AS-BACKING | 1 | |
| 7W0130 | BEARING-THRUST | 1 | |
| 7W0131 | STUD-DRIVE | 3 | |
| 1P1120 | 2 RING-SEAL | 1 | |
| 6N5004 | 3 BEARING-THRUST | 1 | |
| 7N3760 | 4 SHROUD | 1 | |
| 6N6611 | 5 WHEEL & SHAFT AS | 1 | |
| 7N3759 | 6 RING-PISTON | 1 | |
| 9M8915 | 7 RING-RETAINING | 3 | |
| 9N2035 | 8 HOUSING AS-CENTER | 1 | |
| 4M6646 | PIN-GROOVED | 2 | |
| 7W2368 | RING-SEAL | 1 | |
| 9M8911 | 9 COLLAR-THRUST | 1 | |
| 9M8919 | 10 RING-SEAL | 2 | |
| 9N2046 | 11 SPACER-THRUST | 1 | |
| 3S4484 | 12 LOCKNUT-TURBOCHARGER (5/16-24-THD) | 1 | |
| 1W1603 | 13 WHEEL-COMPRESSOR | 1 | |
| 0S1616 | 14 BOLT (1/4-20X1-IN) | 4 | |
| 9N2036 | 15 PLATE-LOCK | 4 | |
| 9N2041 | KIT-BEARING | 1 | |
| 2W0715 | KIT-CARTRIDGE (TURBOCHARGER) | 1 |
