System And Components
247-3784 COVER GP-CYLINDER BLOCK -CENTRAL STRUCTURES/N JKK1-UP
Group No: 247-3784
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N2914 | 1 COVER-CYLINDER BLOCK SIDE | 14 | |
| 4W5015 | 2 COVER | 1 | |
| 5L5840 | 3 WASHER (9.25X16.92X1.83-MM THK) | 8 | |
| 7N3298 | 4 COVER-BLOCK | 3 | |
| 7N4945 | 5 GASKET | 3 | |
| 8N8509 | 6 VALVE GP-EXPLOSION RELIEF (CRANKCASE) | 2 | |
| 8N9992 | 7 COVER-CAMSHAFT | 8 | |
| 3496052 | 8 COVER-CAMSHAFT | 8 | |
| 2985631 | 9 PLATE-IDENTIFICATION (CAT) | 2 | |
| 1A2029 | 10 BOLT (3/8-16X1.125-IN) | 88 | |
| 2720758 | 11 SEAL | 8 | |
| 2720759 | 12 SEAL | 16 | |
| 2775833 | 13 SEAL | 8 | |
| 2301072 | 14 GASKET | 2 | |
| 0S1594 | 15 BOLT (3/8-16X1-IN) | 16 | |
| 0S1595 | 16 BOLT (1/2-13X1.25-IN) | 4 | |
| 1C2251 | 17 BOLT (3/8-16X1.87-IN) | 8 | |
| 3321835 | 18 FILM-WARNING (HOT SURFACE, HANDS CLEAR) | 1 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 160 | |
| 5P8245 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6H6698 | 21 COVER | 2 | |
| 8T6761 | 22 PLUG-PIPE (1-11-1/2 NPT THD) | 2 | |
| 9X8872 | 24 BOLT-LOCKING (3/8-16X0.875-IN) | 60 | |
| 2W3584 | KIT-REPAIR (EXPLOSION RELIEF) | 1 |
