System And Components
200-6405 LINES GP-ENGINE OILS/N JKK1-UP
Group No: 200-6405
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1Y7578 | 1 GASKET-COVER | 1 | |
| 2W1635 | 2 SPRING | 1 | |
| 5R1036 | 3 COVER | 1 | |
| 6B0933 | 4 SPACER (10.31X19.05X6.35-MM THK) | 4 | |
| 8B9725 | 5 BOSS | 4 | |
| 1058901 | 6 GASKET-OIL COOLER | 2 | |
| 1244273 | 7 VALVE-BYPASS | 1 | |
| 1363296 | 8 FLANGE | 1 | |
| 1467359 | 9 TUBE | 1 | |
| 1506611 | 10 BONNET | 1 | |
| 1506612 | 11 ELBOW-OUTLET | 1 | |
| 2445867 | 12 ELBOW | 1 | |
| 2474806 | 13 ELBOW | 1 | |
| 1520993 | 14 TUBE | 1 | |
| 1916695 | 15 PLATE | 1 | |
| 1919310 | 16 COVER | 1 | |
| 1919336 | 17 CORE AS-ENGINE OIL COOLER | 1 | |
| 2859361 | 18 BONNET | 1 | |
| 2869966 | 19 BRACKET | 1 | |
| 1653931 | 20 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1585 | 21 BOLT (1/2-13X1.5-IN) | 2 | |
| 0S1588 | 22 BOLT (3/8-16X1.25-IN) | 8 | |
| 0S1594 | 23 BOLT (3/8-16X1-IN) | 2 | |
| 0S1595 | 24 BOLT (1/2-13X1.25-IN) | 12 | |
| 0S1618 | 25 BOLT (5/16-18X1-IN) | 4 | |
| 0T0065 | 26 BOLT (3/8-16X3.5-IN) | 4 | |
| 1A2029 | 27 BOLT (3/8-16X1.125-IN) | 4 | |
| 3M7045 | 28 PLUG (3/4-14 NPT-THD) | 1 | |
| 3P0653 | 29 SEAL-O-RING | 1 | |
| 2377623 | 30 SEAL-O-RING | 4 | |
| 5M2894 | 31 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5M6213 | 32 PLUG-PIPE (1/4-18-THD) | 1 | |
| 5P4892 | 33 SEAL-O-RING | 1 | |
| 5P5846 | 34 SEAL-O-RING | 1 | |
| 6J2244 | 35 SEAL-O-RING | 1 | |
| 6V3908 | 36 SEAL-O-RING | 1 | |
| 6V6609 | 37 SEAL-O-RING | 2 | |
| 8C3107 | 39 SEAL-O-RING | 1 | |
| 8T6765 | 40 PLUG-PIPE (1/4-18-THD) | 2 | |
| 9M1974 | 41 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9S1366 | 42 BOLT (1/2-13X2.5-IN) | 2 | |
| 9S4185 | 43 PLUG (3/4-16-THD) | 2 |
