System And Components
245-6771 PUMP GP-ENGINE OILS/N XL61-UP; JKK1-UP
Group No: 245-6771
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P5637 | 1 BODY AS-OIL PUMP | 1 | |
| 7W0060 | BUSHING | 3 | |
| 2W6618 | 2 SHAFT AS-PUMP DRIVE | 1 | |
| 2W5479 | 3 SHAFT AS-PUMP | 2 | |
| 7N5052 | GEAR (12-TEETH) | 1 | |
| 7W0050 | 4 COVER AS-PUMP | 1 | |
| 4M3248 | DOWEL-HOLLOW | 2 | |
| 7W0060 | BUSHING | 3 | |
| 0S1585 | 5 BOLT (1/2-13X1.5-IN) | 6 | |
| 1N4637 | 6 COVER AS-PUMP | 1 | |
| 7N2043 | DOWEL | 2 | |
| 5M2894 | 7 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 2S2760 | 8 SPRING | 1 | |
| 7N5057 | 9 GASKET | 1 | |
| 0S1590 | 10 BOLT (3/8-16X2-IN) | 9 | |
| 7N5449 | 11 SPOOL-PRESSURE RELIEF | 1 | |
| 2456770 | 12 COVER | 1 | |
| 1111349 | 13 GASKET | 1 | |
| 7F1866 | 14 BOLT (3/8-16X3-IN) | 2 |
