System And Components
206-4164 LINES GP-AIR -TURBOCHARGER TO AFTERCOOLERS/N JKK1-UP
Group No: 206-4164
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3609687 | 1 GASKET | 2 | |
| 3607990 | 2 GASKET | 1 | |
| 3673918 | 3 HOUSING | 1 | |
| 3442461 | 4 BELLOWS AS | 2 | |
| 3668407 | 5 ELBOW (RH) | 1 | |
| 3668408 | 6 ELBOW (LH) | 1 | |
| 1A5822 | 7 BOLT (1/2-13X2.75-IN) | 8 | |
| 1833407 | 8 PLUG AS | 3 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1653931 | 9 BOLT (3/8-16X1.75-IN) | 4 | |
| 1A1460 | 10 BOLT (1/2-13X2-IN) | 8 | |
| 8S2331 | 11 BOLT-12 POINT HEAD (5/8-11X2-IN) | 5 | |
| 1F7958 | 12 NUT-FULL (1/2-13-THD) | 32 | |
| 5P8245 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 60 | |
| 5P8247 | 14 WASHER-HARD (17X32X3.5-MM THK) | 5 | |
| 9X6458 | 15 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 0L1329 | 16 BOLT (1/2-13X3-IN) | 16 | |
| 1984767 | 17 WASHER-HARD (13.5X30X12-MM THK) | 4 | |
| 2279011 | 18 GASKET | 4 | |
| 3512801 | 19 BRACKET AS | 1 | |
| 3512802 | 20 BRACKET AS | 1 | |
| 3072673 | 21 PLUG AS | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 4391949 | 22 PLUG AS | 1 | |
| 2287101 | SEAL-O-RING | 1 | |
| 2416170 | PLUG | 1 |
