System And Components
392-5216 LINES GP-WATERS/N 2335001-UP
Group No: 392-5216
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3718949 | 1 HOSE (19-CM) | ||
| 6N9590 | 2 PLUG-DRAIN (WATER) | 1 | |
| 6V0675 | 3 ELBOW | 1 | |
| 7E9171 | 4 ADAPTER-PLUG | 1 | |
| 0617208 | 5 CLAMP-TUBE | 1 | |
| 1173335 | 6 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 2446626 | 7 HOSE | 2 | |
| 3272471 | 8 HOSE | 1 | |
| 3399660 | 9 ELBOW | 1 | |
| 3748218 | 10 TUBE AS | 1 | |
| 3756931 | 11 BRACKET | 1 | |
| 3987823 | 12 TUBE | 1 | |
| 4171525 | 13 HOSE AS | 1 | |
| 4250751 | 14 TUBE | 1 | |
| 1488364 | 15 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488365 | 16 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T6876 | ELBOW | 1 | |
| 2094573 | 17 CLAMP-T BOLT | 6 | |
| 2094580 | 18 CLAMP-T BOLT | 4 | |
| 3269712 | 19 SPACER (11.4X25.4X35-MM THK) | 2 | |
| 8M7066 | 20 GASKET | 1 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4182 | 22 BOLT (M10X1.5X45-MM) | 2 | |
| 8T4195 | 23 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4896 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 8T6466 | 25 BOLT (M10X1.5X60-MM) | 2 | |
| 8T9377 | 26 BOLT (3/8-16X2.25-IN) | 2 | |
| 5P0765 | 27 HOSE (11-CM) | ||
| 2S3440 | 28 CLAMP-HOSE | 1 | |
| 2416168 | 29 PLUG AS | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 |
