System And Components
373-3618 CONTROL GP-SERVICE BRAKES/N LFJ1-UP
Group No: 373-3618 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N6984 | 1 MOUNT-RUBBER | 10 | |
| 6U0456 | 2 STRAP | 1 | |
| 9F2167 | 3 SCREW-PURGE (3/8-24X1.164-IN) | 1 | |
| 1088393 | 4 CAP | 1 | |
| 9X8257 | 5 WASHER (17.5X30X3.5-MM THK) | 8 | |
| 1808145 | 6 SEAL | 1 | |
| 2494738 | 7 SPACER (11X20X32-MM THK) | 1 | |
| 2815968 | 8 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T5465 | ELBOW | 1 | |
| 3733620 | 9 TUBE AS | 1 | |
| 3733621 | 10 TUBE AS | 1 | |
| 3733622 | 11 TUBE AS | 1 | |
| 3733637 | 12 HOSE AS | 4 | |
| 3733638 | 13 HOSE AS | 1 | |
| 3733639 | 14 HOSE AS | 1 | |
| 3733642 | 15 HOSE AS | 1 | |
| 3733643 | 16 HOSE AS | 1 | |
| 3733647 | 17 ACCUMULATOR GP-BRAKE (MOUNTING) | 1 | |
| 3745789 | 18 VALVE GP-SOLENOID (24-VOLT)(SERVICE BRAKE) | 1 | |
| 3961162 | 19 TUBE AS | 1 | |
| 3961163 | 20 TUBE AS | 1 | |
| 3961168 | 21 PLATE | 1 | |
| 4217694 | 22 TEE AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 4217685 | ADAPTER-TEE | 1 | |
| 4447046 | 23 CONTROL GP-SERVICE BRAKE | 1 | |
| 1488340 | 24 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488359 | 25 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9877 | ELBOW | 1 | |
| 1488365 | 26 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T6876 | ELBOW | 1 | |
| 1488378 | 27 ELBOW AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488427 | 28 TEE AS | 3 | |
| 6V8398 | SEAL-O-RING | 3 | |
| 8T6895 | TEE-UNION | 1 | |
| 1488444 | 29 TEE AS-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 1495452 | 30 UNION AS (STRAIGHT) | 4 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 1645624 | 31 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 9X2085 | ELBOW | 1 | |
| 1656365 | 32 FITTING AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 7W7381 | FITTING-OUTLET | 1 | |
| 1697403 | 33 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6G3432 | ADAPTER | 1 | |
| 1809286 | 34 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 3E2345 | ADAPTER-TEE | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1833399 | 35 CONNECTOR AS | 2 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1853365 | 36 UNION AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T0129 | UNION | 1 | |
| 2065017 | 37 SPACER (11X20X5-MM THK) | 2 | |
| 1004336 | 38 CLIP (LOOP) | 2 | |
| 6V9168 | 39 NUT (11/16-16-THD) | 4 | |
| 6V9169 | 40 NUT (13/16-16-THD) | 5 | |
| 8T4121 | 41 WASHER-HARD (11X21X2.5-MM THK) | 15 | |
| 8T4123 | 42 WASHER (22X35X3.5-MM THK) | 10 | |
| 8T4186 | 43 BOLT (M10X1.5X40-MM) | 6 | |
| 8T4191 | 44 BOLT (M10X1.5X16-MM) | 4 | |
| 8T4195 | 45 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 46 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4226 | 47 WASHER-PLATED (10.5X45X3-MM THK) | 10 | |
| 8T5005 | 48 BOLT (M10X1.5X70-MM) | 2 | |
| 8T5360 | 49 WASHER (12X22.5X2.5-MM THK) | 2 | |
| 8T6466 | 50 BOLT (M10X1.5X60-MM) | 1 |
