System And Components
396-6882 AFTERCOOLER GP-AIRS/N TFK1-UP
Group No: 396-6882 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3966884 | 1 CORE AS-AFTERCOOLER | 1 | |
| 3966885 | 2 CORE AS-FUEL COOLER | 1 | |
| 6V8721 | ELBOW | 2 | |
| 2287090 | SEAL-O-RING | 2 | |
| 2385081 | SEAL-O-RING | 2 | |
| 3966886 | 3 CORE AS-CONDENSER | 1 | |
| 4259360 | SLEEVE | 4 | |
| 4259361 | MOUNT | 4 | |
| 3966887 | 4 BRACKET (RH) | 1 | |
| 3966888 | 5 BRACKET (LH) | 1 | |
| 3966941 | 6 FRAME AS | 1 | |
| 5C7261 | 7 NUT (M8X1.25-THD) | 4 | |
| 5P4116 | 8 WASHER-HARD (8.8X20.5X2-MM THK) | 10 | |
| 7X7729 | 9 WASHER (11X25X3-MM THK) | 4 | |
| 8T4133 | 10 NUT (M10X1.5-THD) | 4 | |
| 8T4189 | 11 BOLT (M8X1.25X20-MM) | 6 |
