378-7633 LINES GP-COOLING -EMISSIONSS/N TFK1-1294

Group No: 378-7633 · Commonality
Part NumberPart NameQty
3U27521 CLIP (LOOP)4
6U04552 STRAP2
28773413 ELBOW AS2
1248909ELBOW1
3J7354SEAL-O-RING1
34419504 CLIP (SLOT)7
35102715 CONNECTOR AS2
6V9027SEAL-O-RING1
3105893CONNECTOR1
36501627 CONNECTOR-SPECIAL1
39727368 HOSE1
41662219 BRACKET AS1
8T3612NUT-WELD (M8X1.25-THD)1
418436310 HOSE1
422929611 CONNECTOR-SPECIAL1
426999912 HOSE1
427000013 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)1
451040814 ELBOW AS2
6V6609SEAL-O-RING1
1155411ELBOW1
455842515 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)1
8T3597NUT-WELD (M12X1.75-THD)1
8T3612NUT-WELD (M8X1.25-THD)3
455842716 TUBE1
455842817 TUBE1
455842918 TUBE1
124625619 CLAMP-HOSE6
312028820 CLAMP6
343238821 CLIP (LOOP)1
344195122 CLIP (TAB)7
351027523 CONNECTOR AS2
6V3250SEAL-O-RING1
2684045CONNECTOR1
351027624 CONNECTOR AS1
6V3250SEAL-O-RING1
2977964CONNECTOR1
431938825 CLAMP4
433093326 CLAMP2
5C955327 BOLT (M6X1X16-MM)1
5P411628 WASHER-HARD (8.8X20.5X2-MM THK)7
8M277329 CLIP (LOOP)1
8T412130 WASHER-HARD (11X21X2.5-MM THK)4
8T413631 BOLT (M10X1.5X25-MM)4
8T418932 BOLT (M8X1.25X20-MM)3
8T422433 WASHER-HARD (8.8X16X2-MM THK)4
8T489634 WASHER-HARD (10.2X18.5X2.5-MM THK)1
8T490835 BOLT (M8X1.25X25-MM)8
8T937936 BOLT (3/8-16X4.25-IN)1
9X825637 WASHER (6.6X12X2-MM THK)1
332778538 HOSE (100-CM)
332778538A HOSE (63.5-CM)
6V852339 HOSE (91.4-CM)
9X213340 HOSE (95-CM)
9X213340A HOSE (43.1-CM)
9X213340B HOSE (40-CM)
