System And Components
382-1043 HOUSING GP-FLYWHEELS/N TXW754-1771
Group No: 382-1043
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1555619 | 1 GASKET | 1 | |
| 1753721 | 2 COVER | 2 | |
| 3190785 | 3 SEAL GP-CRANKSHAFT (REAR)(FLYWHEEL HOUSING) | 1 | |
| 3821042 | 4 HOUSING AS-FLYWHEEL | 1 | |
| 2098622 | 4A BUSHING | 2 | |
| 1W3136 | 4B BAFFLE | 1 | |
| 1653930 | 5 BOLT (3/8-16X1.625-IN) | 7 | |
| 1653932 | 6 BOLT (3/8-16X2-IN) | 1 | |
| 2234903 | 7 BOLT (3/8-16X5-IN) | 6 | |
| 2348937 | 8 SEAL-INTEGRAL | 1 | |
| 2A1162 | 9 GASKET | 1 | |
| 2P2772 | 10 COVER | 1 | |
| 3072671 | 11 PLUG AS | 4 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3072673 | 12 PLUG AS | 4 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3218642 | 13 PLUG AS | 1 | |
| 9S8003 | PLUG (1/2-20-THD) | 1 | |
| 2147567 | SEAL-O-RING | 1 | |
| 3384562 | 14 BOLT-12 POINT HEAD (1/2-13X3.5 IN) | 8 | |
| 4M0189 | 15 SEAL-O-RING | 2 | |
| 5F0304 | 16 PLUG-DRAIN (5/8-18-THD) | 1 | |
| 5J5793 | 17 BOLT-12 POINT HEAD (1/2-13X2-IN) | 1 | |
| 5P8245 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 13 | |
| 6A5591 | 19 BOLT (M12X1.75X25-MM) | 4 | |
| 6V4248 | 20 BOLT (M10X1.5X25-MM) | 1 | |
| 6V5839 | 21 WASHER (11X21X2.5-MM THK) | 2 | |
| 8T0643 | 22 BOLT (M10X1.5X80-MM) | 1 |
