System And Components
145-3250 BYPASS GP-EXHAUSTS/N XLG1-UP; FPL1-UP
Group No: 145-3250
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C9044 | 1 COVER AS | 1 | |
| 7S7814 | 2 PLATE-RETAINER | 1 | |
| 7S7815 | 3 RETAINER-DIAPHRAGM | 1 | |
| 1131572 | 4 DIAPHRAGM | 1 | |
| 1P0659 | 5 WASHER (0.063-IN THK) | 1 | |
| 7S7816 | 6 LOCKNUT | 1 | |
| 1221159 | 7 BASE AS | 1 | |
| 4P2443 | 8 RETAINER | 1 | |
| 3208921 | 9 SETSCREW (3/8-16X2.5-IN) | 1 | |
| 6V8801 | 10 NUT (3/8-16-THD) | 1 | |
| 3S5849 | 11 GASKET | 2 | |
| 7E4676 | 12 SPRING (INNER) | 1 | |
| 1453249 | 13 VALVE | 1 | |
| 7C9721 | 14 SCREW-MACHINE (1/4-20X2.5-IN) | 5 | |
| 3B4504 | 15 LOCKWASHER | 5 | |
| 7E4677 | 16 SPRING (OUTER) | 1 | |
| 1P9897 | 17 SLEEVE | 1 |
