System And Components
376-2206 BYPASS GP-EXHAUSTS/N XLG1-UP; FPL1-UP
Group No: 376-2206
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3P7019 | 1 SEAL-METAL | 4 | |
| 4W9606 | 2 GASKET | 1 | |
| 4W9607 | 3 ELBOW-BYPASS | 1 | |
| 4W9608 | 4 FLANGE | 1 | |
| 7C9710 | 5 GASKET | 1 | |
| 7M7273 | 6 GASKET | 1 | |
| 9G5127 | 7 BREATHER (ATMOSPHERIC AIR)(EXHAUST BYPASS) | 1 | |
| 1453250 | 8 BYPASS GP-EXHAUST | 1 | |
| 3762212 | 9 ELBOW-EXHAUST | 1 | |
| 3762213 | 10 ADAPTER-EXHAUST | 1 | |
| 4229083 | 11 TUBE AS | 1 | |
| 3762228 | 12 STUD-TAPERLOCK | 4 | |
| 0L1352 | 13 BOLT (3/8-16X3.25-IN) | 1 | |
| 6V3265 | 14 CLIP | 1 | |
| 1687800 | 15 LOCKNUT (3/8-16-THD) | 4 | |
| 3B0645 | 16 PLUG-CUP (32.08-MM OD) | 1 | |
| 4H0553 | 17 FITTING (SPECIAL) | 1 | |
| 4J4382 | 18 PLUG-PIPE (1/2-14-THD) | 1 | |
| 5B7890 | 19 PLUG-PIPE | 2 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5P2603 | 21 STUD-TAPERLOCK (3/8-16X1.57-IN) | 4 | |
| 6W6672 | 22 SPACER (10.5X20X38-MM THK) | 1 | |
| 7C7613 | 23 GASKET-OUTLET | 1 | |
| 7L3195 | 24 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN) | 2 | |
| 0321267 | 25 CONNECTOR (STRAIGHT) | 1 | |
| 0321268 | 26 CONNECTOR (90-DEG) | 1 | |
| 8N8456 | 28 WASHER (10.2X28.5X5-MM THK) | 4 | |
| 8T7353 | 29 BOLT-HIGH TEMPERATURE (M10X1.5X35-MM) | 4 | |
| 9X6458 | 30 WASHER-HARD (10.2X22.5X3-MM THK) | 2 |
