Assembly
100%

377-0709 MANIFOLD GP-EXHAUST -WATER COOLEDS/N XLG1-UP; FPL1-UP

Group No: 377-0709
Part NumberPart NameQty
4N19181 GASKET-WOUND2
4N50372 ELBOW2
4N50383 PIPE2
4N50734 ELBOW6
4N54475 ADAPTER2
4N61456 SUPPORT-MANIFOLD1
12994527 GASKET-EXHAUST MANIFOLD8
28815598 MANIFOLD AS (REAR)1
35469539 MANIFOLD AS (LH)1
354695410 MANIFOLD AS (RH)1
0L135211 BOLT (3/8-16X3.25-IN)3
0L207012 BOLT (3/8-16X2.25-IN)6
0S159013 BOLT (3/8-16X2-IN)6
0S159114 BOLT (3/8-16X1.5-IN)2
0S161915 BOLT (3/8-16X3-IN)8
106179216 STUD-TAPERLOCK (3/8-16X4-IN)16
114922417 SPACER (11.13X19.05X47-MM THK)16
168780018 LOCKNUT (3/8-16-THD)16
5F489919 BOLT (3/8-16X5.5-IN)1
5K595920 SEAL-O-RING8
5M289421 WASHER-HARD (10.2X18.5X2.5-MM THK)51
6V260522 STUD-TAPERLOCK (3/8-16X3.59-IN)1
7C030723 GASKET8
7L052024 STUD-TAPERLOCK (3/8-16X1.968-IN)4
8T676725 PLUG-PIPE (3/8-18-THD)2
9S875226 NUT-FULL (3/8-16-THD)19
