System And Components
422-2052 LINES GP-AIRS/N NAW1-UP
Group No: 422-2052
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N2807 | 1 HOSE | 2 | |
| 1270929 | 2 CLAMP-V BAND | 2 | |
| 3065412 | 3 HOSE | 2 | |
| 3546454 | 4 STRAP | 3 | |
| 3546488 | 5 TUBE AS | 1 | |
| 3546489 | 6 TUBE AS | 1 | |
| 3842242 | 7 TUBE AS | 1 | |
| 3842243 | 8 BRACKET | 1 | |
| 8T4195 | 9 BOLT (M10X1.5X30-MM) | 6 | |
| 3429913 | 10 BOLT-FLANGE HEAD (M10X1.5X20-MM) | 1 | |
| 8C3089 | 11 SEAL-O-RING | 2 | |
| 1984777 | 12 WASHER-HARD (11X25X10-MM THK) | 6 | |
| 8T4985 | 13 CLAMP-HOSE | 4 | |
| 9X2201 | 14 CLAMP-HOSE | 4 |
