System And Components
477-2059 EXHAUST GPS/N GB31-UP
Group No: 477-2059
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W7861 | 1 FLANGE-EXHAUST | 1 | |
| 0897959 | 2 SCREW (TAPPING) | 50 | |
| 3699781 | 3 BELLOWS AS | 1 | |
| 3710945 | 4 GASKET-EXHAUST OUTLET FLANGE | 1 | |
| 3710946 | 5 GASKET-EXHAUST | 1 | |
| 3841800 | 6 MUFFLER AS | 1 | |
| 3895695 | 7 ADAPTER AS-EXHAUST | 1 | |
| 4770010 | 9 SUPPRESSION AS | 1 | |
| 4M1217 | STUD-WELD | 8 | |
| 4770011 | 10 PIPE AS | 1 | |
| 1A1460 | 11 BOLT (1/2-13X2-IN) | 34 | |
| 1F7958 | 12 NUT-FULL (1/2-13-THD) | 30 | |
| 2W7862 | 13 GASKET-EXHAUST | 1 | |
| 2W7865 | 14 GASKET-EXHAUST | 3 | |
| 5L4398 | 15 BOLT (1/2-13X2.25-IN) | 4 | |
| 5P8245 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 68 | |
| 6V8188 | 17 NUT (1/2-13-THD) | 8 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 8 |
