System And Components
417-8440 LINES GP-AIRFOR USE WITH RH ENGINE MOUNTED SEC FUEL FILTER
Group No: 417-8440
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9N5085 | 1 CLAMP | 1 | |
| 3537160 | 2 BRACKET AS | 1 | |
| 4209300 | 3 TUBE-VENTURI | 1 | |
| 3808558 | 4 HOSE | 2 | |
| 4503125 | 5 TUBE-AIR | 1 | |
| 3147599 | 6 CLAMP-BAND | 4 | |
| 3233729 | 7 STUD (M8X1.25X97.6-MM) | 1 | |
| 5P5757 | 8 SEAL-O-RING | 1 | |
| 5P8245 | 9 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V5684 | 10 BOLT (M12X1.75X45-MM) | 2 | |
| 8T0100 | 11 BOLT (M8X1.25X60-MM) | 1 | |
| 9M1974 | 12 WASHER-HARD (8.8X16X2-MM THK) | 2 |
