System And Components
398-3943 LINES GP-TURBOCHARGERType 2
Group No: 398-3943
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2901993 | 1 STRAP-CABLE | 3 | |
| 3177012 | 2 CLAMP-BAND | 2 | |
| 4480604 | 3 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 3559439 | 4 BRACKET AS | 1 | |
| 3649626 | 5 ELBOW AS | 1 | |
| 2147567 | SEAL-O-RING | 1 | |
| 3649625 | ADAPTER-ELBOW | 1 | |
| 3649628 | 6 ELBOW AS | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3649627 | ADAPTER-ELBOW | 1 | |
| 3649632 | 7 ELBOW AS | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3649631 | ADAPTER-ELBOW | 1 | |
| 3659305 | 8 TUBE AS | 1 | |
| 3669285 | 9 TUBE AS-AIR | 1 | |
| 3993284 | 10 BRACKET AS | 1 | |
| 9M1974 | 11 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 1783336 | 12 NUT-HEX FLANGE (M8X1.25-THD) | 3 | |
| 2049734 | 13 SPACER (11X18X25-MM THK) | 1 | |
| 3453350 | 15 CLIP | 2 | |
| 3993290 | 16 TUBE AS-AIR | 1 | |
| 6V4248 | 17 BOLT (M10X1.5X25-MM) | 2 | |
| 6V5215 | 18 BOLT (M8X1.25X16-MM) | 1 | |
| 6V5839 | 19 WASHER (11X21X2.5-MM THK) | 3 | |
| 8T0276 | 20 BOLT (M8X1.25X45-MM) | 1 | |
| 3630253 | 21 CLIP (TAB) | 2 | |
| 3630254 | 22 CLIP (SLOT) | 2 | |
| 6V5217 | 23 BOLT (M8X1.25X20-MM) | 1 | |
| 3374178 | 24 HOSE (24-CM) | ||
| 3304374 | 25 SLEEVE (30-CM) |
