Assembly
100%

398-3942 LINES GP-TURBOCHARGER AIRType 2

Group No: 398-3942
Part NumberPart NameQty
29019931 STRAP-CABLE3
31770122 CLAMP-BAND2
44806043 BRACKET AS1
8T3612NUT-WELD (M8X1.25-THD)1
35594394 BRACKET AS1
35890915 BRACKET AS1
36496266 ELBOW AS1
2147567SEAL-O-RING1
3649625ADAPTER-ELBOW1
36496287 ELBOW AS1
2147566SEAL-O-RING1
3649627ADAPTER-ELBOW1
36496328 ELBOW AS1
2385080SEAL-O-RING1
3649631ADAPTER-ELBOW1
36692859 TUBE AS-AIR1
448688210 TUBE AS-AIR1
399328011 TUBE AS-AIR1
399328412 BRACKET AS1
6V521713 BOLT (M8X1.25X20-MM)1
178333614 NUT-HEX FLANGE (M8X1.25-THD)3
204973415 SPACER (11X18X25-MM THK)1
342213416 CLIP1
345335017 CLIP2
6V424818 BOLT (M10X1.5X25-MM)2
6V521519 BOLT (M8X1.25X16-MM)1
6V521820 BOLT (M8X1.25X35-MM)1
6V583921 WASHER (11X21X2.5-MM THK)4
6V821222 BOLT (M10X1.5X16-MM)1
8T027623 BOLT (M8X1.25X45-MM)1
9M197424 WASHER-HARD (8.8X16X2-MM THK)4
337417825 HOSE (24-CM)
330437426 SLEEVE (30-CM)
363025427 CLIP (SLOT)2
363025328 CLIP (TAB)2
