System And Components
416-4725 VALVE GP-AIR CONTROLPART OF 394-5351, 394-5352, 394-5356, 394-5357, 394-5358, 394-5359 MODULE AR-CLEAN EMISSIONS
Group No: 416-4725
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3438109 | 1 ELBOW-OUTLET | 1 | |
| 3470925 | 2 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3473242 | 3 PLATE | 1 | |
| 3653006 | 4 VALVE GP-AIR CONTROL | 1 | |
| 3488778 | SEAL | 1 | |
| 3893708 | 5 PLUG AS | 2 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 4152405 | 6 MANIFOLD GP-INLET | 1 | |
| 4152415 | 7 HOSE-AIR | 1 | |
| 4164732 | 8 TUBE AS | 1 | |
| 4164733 | 9 ELBOW-AIR INLET | 1 | |
| 1246275 | 10 CLAMP-HOSE | 2 | |
| 1917805 | 11 ELBOW AS | 1 | |
| 0307947 | ADAPTER-ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2147568 | 12 SEAL-O-RING | 1 | |
| 2422961 | 13 SPACER (7X16X12-MM THK) | 4 | |
| 8T6869 | 14 BOLT (M8X1.25X60-MM) | 4 | |
| 3118366 | 15 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 3441195 | 16 BOLT (M8X1.25X100-MM) | 2 | |
| 3441198 | 17 BOLT (M6X1X45-MM) | 2 | |
| 3441200 | 18 WASHER-HARD (6.6X12X2-MM THK) | 5 | |
| 3441206 | 19 BOLT (M6X1X16-MM) | 1 | |
| 3441208 | 20 BOLT (M6X1X35-MM) | 2 | |
| 5P4924 | 21 ELBOW | 1 |
