System And Components
500-2526 LINES GP-PUMPS/N MG51-UP; GB61-UP
Group No: 500-2526
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5F3106 | 1 SEAL-O-RING | 1 | |
| 8T4136 | 2 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4137 | 3 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4183 | 4 BOLT (M12X1.75X40-MM) | 2 | |
| 8T4185 | 5 BOLT (M10X1.5X50-MM) | 2 | |
| 8T4186 | 6 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4191 | 7 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4195 | 8 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 9 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4910 | 10 BOLT (M12X1.75X60-MM) | 3 | |
| 1488442 | 11 TEE AS | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8T1685 | TEE | 1 | |
| 1P4577 | 12 FLANGE-HALF | 2 | |
| 3K0360 | 13 SEAL-O-RING | 1 | |
| 4J0520 | 14 SEAL-O-RING | 1 | |
| 4P7581 | 15 CLIP (LADDER) | 1 | |
| 5P4961 | 16 CLAMP-HOSE | 2 | |
| 7X0618 | 17 WASHER-HARD (13.5X40X5-MM THK) | 3 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4956 | 20 BOLT (M12X1.75X35-MM) | 4 | |
| 9U6994 | 21 ADAPTER AS | 1 | |
| 5P4362 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1093001 | 22 STUD-TAPERLOCK (M10X1.5X65-MM) | 1 | |
| 1337810 | 23 STUD-TAPERLOCK (M10X1.5X45-MM) | 1 | |
| 1488316 | 24 CONNECTOR AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 1488345 | 25 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 1488347 | 26 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488353 | 27 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488365 | 28 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T6876 | ELBOW | 1 | |
| 1488388 | 29 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8629 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488390 | 30 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8626 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488392 | 31 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9853 | ELBOW | 1 | |
| 1503030 | 32 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 7X1448 | ELBOW | 1 | |
| 1602669 | 33 ACCUMULATOR GP-HYDRAULIC (CHARGED) | 1 | |
| 1608616 | 34 VALVE GP-CHECK | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1645574 | 35 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8784 | TEE-FACE SEAL | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1694019 | 36 FILTER GP-OIL (HYDRAULIC) | 1 | |
| 1757141 | 37 NUT-HEX FLANGE (M10X1.5-THD) | 4 | |
| 1942903 | 38 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 8T0119 | ELBOW | 1 | |
| 1984777 | 39 WASHER-HARD (11X25X10-MM THK) | 2 | |
| 2042281 | 40 STRAP-CABLE | 2 | |
| 3188481 | 41 PUMP GP-PISTON (IMPLEMENT) | 1 | |
| 3410108 | 42 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 3410107 | ELBOW | 1 | |
| 3445675 | 43 NUT (M10X1.5-THD) | 3 | |
| 4368105 | 44 TUBE AS | 1 | |
| 4479443 | 45 BRACKET AS | 1 | |
| 4495044 | 46 CLAMP AS | 2 | |
| 4509730 | 47 BRACKET AS | 1 | |
| 4638061 | 48 TUBE AS | 1 | |
| 4760700 | 49 PLATE | 2 | |
| 4805360 | 50 BRACKET AS | 1 | |
| 5070014 | 51 HOSE AS | 1 | |
| 5070015 | 52 HOSE AS | 1 | |
| 5070016 | 53 HOSE AS | 1 | |
| 5070017 | 54 HOSE AS | 1 | |
| 5070018 | 55 HOSE AS | 1 | |
| 5070019 | 56 HOSE AS | 1 | |
| 5070020 | 57 HOSE AS | 1 | |
| 5070021 | 58 HOSE AS | 1 | |
| 2684412 | TAPE-INSULATOR | ||
| 3263570 | INSULATION (43-CM) | ||
| 4206343 | HOSE | 1 | |
| 5070022 | 59 HOSE AS | 1 | |
| 2684412 | TAPE-INSULATOR | ||
| 3249707 | INSULATION (45-CM) | ||
| 4469653 | HOSE AS | 1 | |
| 5070023 | 60 HOSE AS | 1 | |
| 2684412 | TAPE-INSULATOR | ||
| 3263570 | INSULATION (49-CM) | ||
| 4206380 | HOSE | 1 | |
| 5070024 | 61 HOSE AS | 1 | |
| 3249708 | INSULATION (15-CM) | ||
| 2684412 | TAPE-INSULATOR | ||
| 5P2094 | HOSE (22-CM) | ||
| 5070025 | 62 HOSE AS | 1 | |
| 3263566 | INSULATION (59-CM) | ||
| 2684412 | TAPE-INSULATOR | ||
| 1226869 | HOSE-HYDRAULIC (27-IN) | ||
| 1497738 | 63 CLIP (LOOP) | 1 | |
| 1504049 | 64 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8T4149 | ELBOW | 1 | |
| 1772215 | 65 STRAP-DUAL CLAMP | 1 | |
| 2006345 | 66 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2245445 | 67 STUD-TAPERLOCK (M10X1.5X75-MM) | 4 | |
| 3159860 | 68 ADAPTER AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8C3051 | ADAPTER | 1 | |
| 3918044 | 69 CLIP (LOOP) | 1 | |
| 4D7735 | 70 CLIP | 1 | |
| 4J0527 | 71 SEAL-O-RING | 1 | |
| 4S4455 | 72 CLIP | 1 | |
| 5P7468 | 73 CLIP (SLOT) | 1 | |
| 5P7469 | 74 CLIP (TAB) | 1 | |
| 6D3479 | 75 CLIP (LOOP) | 2 | |
| 6K8178 | 76 CLIP (LOOP) | 1 | |
| 6V1889 | 77 CLIP (LOOP) | 3 | |
| 7X7958 | 78 CLAMP-HOSE | 4 | |
| 8S0948 | 79 CLIP | 1 | |
| 8T4648 | 80 BOLT (M12X1.75X70-MM) | 2 | |
| 8T6703 | 81 CLAMP-HOSE | 4 | |
| 9U6999 | 82 ELBOW AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 0344202 | ELBOW | 1 |
