System And Components
376-1506 AIR CLEANER GPS/N WTS1-UP
Group No: 376-1506
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3870534 | 1 HOSE AS | 1 | |
| 3914394 | 2 AIR CLEANER GP | 1 | |
| 5230639 | 3 TUBE | 1 | |
| 4289359 | 4 PLATE AS | 1 | |
| 4570032 | 5 INSULATION | 1 | |
| 4947167 | 6 COVER AS | 1 | |
| 6V1634 | RIVET-POP | 14 | |
| 1983899 | 7 SCREW-BUTTON HEAD (M8X1.25X20-MM) | 9 | |
| 3464792 | 8 CLAMP-BAND | 1 | |
| 3709563 | 9 SPACER (13.5X25X12-MM THK) | 2 | |
| 5P4116 | 10 WASHER-HARD (8.8X20.5X2-MM THK) | 13 | |
| 7X7729 | 11 WASHER (11X25X3-MM THK) | 6 | |
| 8T4182 | 12 BOLT (M10X1.5X45-MM) | 2 | |
| 8T4189 | 13 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4196 | 14 BOLT (M10X1.5X35-MM) | 6 | |
| 8T4222 | 15 WASHER-PLATED (11X32X2.5-MM THK) | 2 | |
| 8T4984 | 16 CLAMP-HOSE | 2 | |
| 8T4989 | 17 CLAMP-HOSE | 1 | |
| 8T6703 | 18 CLAMP-HOSE | 2 | |
| 9D6196 | 19 CLIP (SLOT) | 2 | |
| 9D6197 | 20 CLIP (TAB) | 2 | |
| 5149005 | 21 HOSE | 1 | |
| 5P1293 | 22 HOSE (16-CM) | ||
| 5P8309 | 23 SEAL (1.3-M) |
