System And Components
415-8032 VALVE GP-AIR CONTROLS/N WTS1-UP
Group No: 415-8032
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3438109 | 1 ELBOW-OUTLET | 1 | |
| 3653006 | 2 VALVE GP-AIR CONTROL | 1 | |
| 3855773 | 3 CONNECTOR AS | 2 | |
| 5P1046 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3893708 | 4 PLUG AS | 2 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 4152405 | 5 MANIFOLD GP-INLET | 1 | |
| 4152415 | 6 HOSE-AIR | 1 | |
| 4152416 | 7 ELBOW-AIR INLET | 1 | |
| 4182053 | 8 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 1246275 | 9 CLAMP-HOSE | 2 | |
| 1860815 | 10 BOLT (M6X1X20-MM) | 2 | |
| 2653253 | 11 BOLT (M8X1.25X60-MM) | 4 | |
| 3118366 | 12 WASHER-HARD (8.8X16X2-MM THK) | 10 | |
| 3441193 | 13 BOLT (M8X1.25X25-MM) | 4 | |
| 3441195 | 14 BOLT (M8X1.25X100-MM) | 2 | |
| 3441200 | 15 WASHER-HARD (6.6X12X2-MM THK) | 2 |
