System And Components
527-6952 BELT TENSIONER GP -FANS/N K3B692-UP
Group No: 527-6952
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4632193 | 1 NUT-O-RING SEAL (M36X2-THD)(M36X2-THD) | 1 | |
| 4713736 | 2 WASHER-HARD | 1 | |
| 5276950 | 3 PULLEY (3-GROOVE) | 1 | |
| 5276951 | 4 SHAFT (TENSIONER) | 1 | |
| 5392747 | 5 BRACKET | 1 | |
| 2398111 | 6 RING-RETAINING | 1 | |
| 2968187 | 7 BOLT (M12X1.75X191.5-MM) | 1 | |
| 6V1394 | 8 BALL BEARING (SPL) | 2 | |
| 8T4223 | 9 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4244 | 10 NUT (M12X1.75-THD) | 2 |
