System And Components
350-7156 DRIVE GP-FANS/N K3B692-UP
Group No: 350-7156
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2892498 | 1 BRACKET | 1 | |
| 3925072 | 2 PLATE AS | 1 | |
| 3990332 | 3 SPACER | 1 | |
| 3936154 | 4 DRIVE AS-FAN | 1 | |
| 3098037 | 5 BELT TENSIONER GP (FAN) | 1 | |
| 1984767 | 6 WASHER-HARD (13.5X30X12-MM THK) | 4 | |
| 2229151 | 7 WASHER-HARD (11X32X5-MM THK) | 1 | |
| 1759079 | 8 ROD-LINK | 1 | |
| 5P8245 | 9 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 6V8004 | 10 BOLT (M12X1.75X120-MM) | 4 | |
| 6V8149 | 11 NUT (M12X1.75-THD) | 2 | |
| 6V8336 | 12 BOLT (M12X1.75X70-MM) | 3 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4133 | 14 NUT (M10X1.5-THD) | 3 | |
| 8T4172 | 15 BOLT (M10X1.5X80-MM) | 2 | |
| 8T4186 | 16 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4196 | 17 BOLT (M10X1.5X35-MM) | 1 | |
| 8T6466 | 18 BOLT (M10X1.5X60-MM) | 2 |
