System And Components
441-9579 DRIVE GP-FANS/N K3B692-UP
Group No: 441-9579
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N6423 | 1 V-BELT SET (FAN DRIVE) | 1 | |
| 2892498 | 2 BRACKET | 1 | |
| 5610463 | 3 BELT TENSIONER GP | 1 | |
| 3487023 | 4 DRIVE GP-FAN | 1 | |
| 3990332 | 5 SPACER | 1 | |
| 4422371 | 6 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4664167 | 7 PULLEY-FAN DRIVE | 1 | |
| 4500998 | 8 SPACER (13.5X25X12-MM THK) | 1 | |
| 1759079 | 9 ROD-LINK | 1 | |
| 2229151 | 10 WASHER-HARD (11X32X5-MM THK) | 1 | |
| 1018917 | 11 STUD-TAPERLOCK (3/8-16X4.5-IN) | 6 | |
| 5M2894 | 12 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5P8245 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 9 | |
| 6V5839 | 14 WASHER (11X21X2.5-MM THK) | 1 | |
| 8T5041 | 15 BOLT (M12X1.75X120-MM) | 4 | |
| 6V8149 | 16 NUT (M12X1.75-THD) | 2 | |
| 6V8197 | 17 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 13 | |
| 8T4133 | 19 NUT (M10X1.5-THD) | 4 | |
| 8T4172 | 20 BOLT (M10X1.5X80-MM) | 2 | |
| 6V4249 | 21 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4186 | 22 BOLT (M10X1.5X40-MM) | 2 | |
| 1837121 | 23 BOLT (M10X1.5X35-MM) | 1 | |
| 8T6466 | 24 BOLT (M10X1.5X60-MM) | 2 | |
| 9S8752 | 25 NUT-FULL (3/8-16-THD) | 6 |
