System And Components
348-2906 LINES GP-AIRS/N X3F1-UP
Group No: 348-2906
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2177088 | 1 HOSE | 2 | |
| 2252615 | 2 LINES GP-AIR | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 8C3089 | SEAL-O-RING | 1 | |
| 1270929 | CLAMP-V BAND | 1 | |
| 2178946 | ELBOW | 1 | |
| 2840671 | 3 CLAMP-BAND | 1 | |
| 3259616 | 4 HOSE | 1 | |
| 3351184 | 5 ELBOW-AIR | 1 | |
| 3476894 | 6 HOSE | 1 | |
| 3845277 | 7 TUBE AS | 1 | |
| 3845278 | 8 TUBE | 1 | |
| 3845281 | 9 BRACKET | 1 | |
| 3845282 | 10 BRACKET | 1 | |
| 3845283 | 11 BRACKET | 1 | |
| 1565745 | 12 CLAMP-HALF | 6 | |
| 1F3584 | 13 SPACER (11X20X25-MM THK) | 1 | |
| 2087448 | 14 CLAMP | 11 | |
| 5P1076 | 15 WASHER-HARD (13.5X30X4-MM THK) | 10 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4133 | 17 NUT (M10X1.5-THD) | 2 | |
| 8T4137 | 18 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4183 | 19 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4184 | 20 BOLT (M12X1.75X45-MM) | 2 | |
| 8T4195 | 21 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4244 | 23 NUT (M12X1.75-THD) | 6 | |
| 9X2027 | 24 WASHER (11X18X2-MM THK) | 2 |
