System And Components
442-7265 LINES GP-AIRS/N X3F1-UP
Group No: 442-7265
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2177088 | 1 HOSE | 2 | |
| 2252615 | 2 LINES GP-AIR | 1 | |
| 8C3089 | SEAL-O-RING | 1 | |
| 1270929 | CLAMP-V BAND | 1 | |
| 2178946 | ELBOW | 1 | |
| 2840671 | 3 CLAMP-BAND | 1 | |
| 3259616 | 4 HOSE | 1 | |
| 3351184 | 5 ELBOW-AIR | 1 | |
| 3476894 | 6 HOSE | 1 | |
| 3828078 | 7 CLAMP | 1 | |
| 3845278 | 8 TUBE | 1 | |
| 4922280 | 9 BRACKET | 1 | |
| 4405133 | 10 BRACKET | 1 | |
| 4414308 | 11 TUBE AS | 1 | |
| 1565745 | 12 CLAMP-HALF | 6 | |
| 2087448 | 13 CLAMP | 11 | |
| 5P1076 | 14 WASHER-HARD (13.5X30X4-MM THK) | 10 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4133 | 16 NUT (M10X1.5-THD) | 2 | |
| 8T4183 | 17 BOLT (M12X1.75X40-MM) | 6 | |
| 8T4195 | 18 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4244 | 20 NUT (M12X1.75-THD) | 6 | |
| 9X2027 | 21 WASHER (11X18X2-MM THK) | 2 |
