System And Components
123-7869 LINES GP-TRANSMISSION OILS/N 9LR383-561
Group No: 123-7869
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7U4245 | 1 SCREEN & MTG GP-TRANSMISSION | 1 | |
| 5P1293 | 2 HOSE (26-CM) | ||
| 5P1293 | 2A HOSE (14-CM) | ||
| 7U6696 | 3 TUBE | 1 | |
| 5U6440 | 4 CLAMP | 6 | |
| 7U3731 | 5 TUBE AS-SUCTION | 1 | |
| 4B5881 | 6 GASKET | 1 | |
| 5S7382 | 7 BOLT (3/8-16X1.375-IN) | 19 | |
| 8T4896 | 8 WASHER-HARD (10.2X18.5X2.5-MM THK) | 23 | |
| 7U6365 | 9 PUMP GP-TRANSMISSION | 1 | |
| 5U5128 | 10 PIPE AS | 1 | |
| 1P4579 | 11 FLANGE-HALF | 20 | |
| 8T8919 | 12 BOLT (1/2-13X1.75-IN) | 28 | |
| 8T4223 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 38 | |
| 4J0524 | 14 SEAL-O-RING | 11 | |
| 7U6366 | 15 HOSE AS | 1 | |
| 0307935 | 16 CONNECTOR | 1 | |
| 0307966 | 17 ELBOW | 1 | |
| 0094440 | 18 CONNECTOR | 1 | |
| 7M8485 | 19 SEAL-O-RING | 1 | |
| 1112073 | 20 MANIFOLD | 1 | |
| 1010387 | 21 CONNECTOR | 1 | |
| 6V8397 | 22 SEAL-O-RING | 14 | |
| 7U4546 | 23 FLANGE | 1 | |
| 4J0522 | 24 SEAL-O-RING | 9 | |
| 7X0314 | 25 BOLT (7/16-14X3-IN) | 4 | |
| 8T5360 | 26 WASHER (12X22.5X2.5-MM THK) | 28 | |
| 1303913 | 27 HOSE AS | 1 | |
| 6V8627 | 28 ELBOW | 3 | |
| 6V8628 | 29 ELBOW | 1 | |
| 3J1907 | 30 SEAL-O-RING | 14 | |
| 3J7354 | 31 SEAL-O-RING | 4 | |
| 4J5477 | 32 SEAL-O-RING | 15 | |
| 7U5947 | 33 HOSE AS | 1 | |
| 1P4578 | 34 FLANGE-HALF | 14 | |
| 8T8916 | 35 BOLT (7/16-14X1.5-IN) | 20 | |
| 5P7470 | 36 CLIP (SLOT) | 1 | |
| 5P7471 | 37 CLIP (TAB) | 1 | |
| 5P7703 | 38 GROMMET (52-MM ID) | 1 | |
| 5U9349 | 39 BRACKET | 1 | |
| 3E9257 | 40 VALVE GP-SOLENOID | 1 | |
| 6V8188 | 41 NUT (1/2-13-THD) | 3 | |
| 7T9745 | 42 MANIFOLD-VALVE | 1 | |
| 6V8801 | 44 NUT (3/8-16-THD) | 3 | |
| 2W8744 | 45 STRIP | 1 | |
| 6P4603 | 46 FILTER GP-OIL (TRANSMISSION) | 1 | |
| 6V8774 | 48 TEE | 3 | |
| 7U5935 | 49 HOSE AS | 1 | |
| 8C3446 | 50 VALVE-SAMPLING (TRANSMISSION OIL) | 1 | |
| 8C3447 | 51 CAP-DUST | 1 | |
| 8C6865 | 52 CONNECTOR | 1 | |
| 6V0852 | 53 CAP-DUST | 3 | |
| 6V3965 | 54 FITTING (QUICK DISCONNECT) | 3 | |
| 7X7945 | 55 ADAPTER (9/16-18-THD) | 2 | |
| 2P1279 | 56 LOCKNUT (9/16-18-THD) | 2 | |
| 7X0311 | 57 BOLT (7/16-14X2.25-IN) | 4 | |
| 7U5928 | 58 HOSE AS | 1 | |
| 1043899 | 59 VALVE GP-CHECK | 1 | |
| 8T6663 | 60 ADAPTER-PORT | 1 | |
| 8C6866 | 61 CONNECTOR | 1 | |
| 4H6112 | 62 BREATHER (TRANSMISSION) | 1 | |
| 7X2444 | 63 TEE-SWIVEL | 2 | |
| 7U4308 | 70 HOSE AS | 1 | |
| 9L7494 | 71 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 2 | |
| 6V1722 | 72 ADAPTER | 1 | |
| 3D2824 | 74 SEAL-O-RING | 2 | |
| 3K0360 | 75 SEAL-O-RING | 6 | |
| 6V8398 | 76 SEAL-O-RING | 2 | |
| 7U7111 | 77 PIPE AS | 1 | |
| 1P4577 | 78 FLANGE-HALF | 6 | |
| 4J0520 | 79 SEAL-O-RING | 3 | |
| 1081189 | 80 TUBE AS | 1 | |
| 7U7699 | 81 TUBE AS | 1 | |
| 7U7112 | 82 PIPE AS | 1 | |
| 5U2885 | 83 HOSE AS | 1 | |
| 1638444 | 84 HOSE AS | 2 | |
| 1278447 | 85 HOSE AS | 1 | |
| 1278445 | 86 HOSE AS | 1 | |
| 6V9010 | 87 CONNECTOR-PORT | 1 | |
| 6V8625 | 88 ELBOW | 2 | |
| 5P2566 | 89 BOLT (1/2-13X1.5-IN) | 6 | |
| 7U5949 | 90 HOSE AS | 1 | |
| 8C4436 | 91 BOLT (1/2-13X1.375-IN) | 1 | |
| 6V9849 | 92 ELBOW | 3 | |
| 5P7464 | 93 CLIP (SLOT) | 1 | |
| 5P7465 | 94 CLIP (TAB) | 1 | |
| 6V1249 | 95 GROMMET (22-MM ID) | 1 | |
| 7U6367 | 96 HOSE AS | 1 | |
| 8S0024 | 97 CLIP (TAB) | 2 | |
| 2D7325 | 102 TEE-PIPE | 1 | |
| 4S6399 | 104 CONNECTOR | 1 | |
| 3P1932 | 105 ADAPTER | 1 | |
| 0307946 | 106 ELBOW | 1 | |
| 5U7601 | 107 HOSE AS | 1 | |
| 8S0023 | 108 CLIP (SLOT) | 2 | |
| 7U7696 | 109 TUBE AS | 1 | |
| 7U7698 | 110 TUBE AS | 1 | |
| 9S1912 | 111 JOINT AS-TUBE | 2 | |
| 1P1033 | SEAL | 2 | |
| 1087627 | 115 HOSE AS | 1 | |
| 6V8634 | 119 CONNECTOR | 2 | |
| 2U7629 | 121 HOSE AS | 1 | |
| 1255366 | 123 HOSE AS | 1 | |
| 6V9872 | 124 CONNECTOR | 1 | |
| 1255365 | 125 HOSE AS | 1 | |
| 8T2501 | 128 BOLT (3/8-16X2-IN) | 2 | |
| 2P8421 | 129 ADAPTER-O-RING | 1 | |
| 8T4205 | 132 WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 0S1597 | 133 BOLT (1/4-28X1-IN) | 8 | |
| 6V9001 | 137 ELBOW | 2 | |
| 4E6888 | 138 HOSE AS | 1 | |
| 4E5259 | 139 HOSE AS | 1 | |
| 8T3311 | 141 TEE | 1 | |
| 6V9850 | 142 ELBOW | 1 | |
| 1146652 | 143 HOSE AS | 1 | |
| 1477311 | 144 ACCUMULATOR GP (UNCHARGED) | 1 |
