System And Components
360-0309 FILLER GP-POWER TRAIN OILS/N TNS1-UP
Group No: 360-0309
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P7175 | 1 FITTING-STRAIGHT | 1 | |
| 9G5127 | 2 BREATHER (ATMOSPHERIC AIR)(POWER TRAIN OIL) | 1 | |
| 1785210 | 3 ELBOW | 1 | |
| 2977987 | 4 ELBOW | 1 | |
| 3686468 | 5 COVER GP-XMSN OIL FILLER CAP | 1 | |
| 3762204 | 6 GAUGE GP-SIGHT (POWER TRAIN OIL) | 1 | |
| 5J2974 | SEAL-O-RING | 4 | |
| 1228353 | BOLT (M12X1.75X46.5-MM) | 2 | |
| 3916961 | 7 BRACKET AS | 1 | |
| 3916983 | 8 TUBE AS | 1 | |
| 3916984 | 9 HOSE | 1 | |
| 8T4983 | 10 CLAMP-HOSE | 2 | |
| 1769237 | 11 BOLT-SPECIAL (M10X1.5-THD) | 1 | |
| 5H2730 | 12 GASKET | 1 | |
| 5P4961 | 13 CLAMP-HOSE | 2 | |
| 5P7468 | 14 CLIP (SLOT) | 2 | |
| 5P7469 | 15 CLIP (TAB) | 2 | |
| 5P8444 | 16 GROMMET (37-MM ID) | 2 | |
| 6V5048 | 17 SEAL-O-RING | 1 | |
| 8S7169 | 18 COUPLING | 1 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4133 | 20 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 21 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4195 | 22 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4223 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4956 | 24 BOLT (M12X1.75X35-MM) | 2 | |
| 8T6466 | 25 BOLT (M10X1.5X60-MM) | 1 | |
| 9C5344 | 26 SPACER (10.5X20X18-MM THK) | 1 | |
| 9M8406 | 27 CLIP (LOOP) | 3 | |
| 4231982 | 28 HOSE (45-IN) |
