System And Components
8E-0305 CLUTCH & GEAR GPS/N 7BG1-UP
Group No: 8E-0305
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9G5655 | 1 MANIFOLD AS | 1 | |
| 4B9783 | BALL | 1 | |
| 5K4781 | 2 BOLT-SPECIAL | 2 | |
| 7S3002 | 3 BALL BEARING | 2 | |
| 7G4822 | 4 RING-SEAL | 2 | |
| 7T7824 | 5 BUSHING | 1 | |
| 9G6604 | 6 HOUSING AS | 1 | |
| 8B1312 | DOWEL | 2 | |
| 0L1352 | 7 BOLT (3/8-16X3.25-IN) | 8 | |
| 7G9261 | 8 PISTON | 1 | |
| 7G9233 | 9 RING-SEAL | 1 | |
| 3P5726 | 10 RING-SEAL | 1 | |
| 7G9263 | 11 CAGE | 1 | |
| 7G9234 | 12 PLATE-CLUTCH | 4 | |
| 6T1783 | 13 DISC-FRICTION | 4 | |
| 9P9204 | 14 SPRING | 8 | |
| 7G9231 | 15 DOWEL | 12 | |
| 7G9257 | 16 HUB-CLUTCH | 1 | |
| 6T2799 | 17 GEAR-INPUT (45-TEETH) | 1 | |
| 5P7655 | 18 BEARING | 1 | |
| 0616711 | 19 RING-RETAINING | 1 | |
| 1A2029 | 20 BOLT (3/8-16X1.125-IN) | 8 | |
| 1J2859 | 21 SEAL-O-RING | 1 | |
| 3T8849 | 22 RETAINER-SEAL | 1 | |
| 0L1351 | 23 BOLT (3/8-16X0.875-IN) | 5 | |
| 4B8024 | 24 SEAL-LIP TYPE | 1 | |
| 3T8847 | 25 COUPLING | 1 | |
| 7J6580 | 26 RING-RETAINING | 1 | |
| 2H3927 | 27 SEAL-O-RING | 1 | |
| 7M7260 | 28 GASKET-LIQUID (8-OZ CAN) | ||
| 3K3138 | 29 RING-RETAINING | 1 | |
| 1K7019 | 30 SHIM (0.02-IN THK) | 5 | |
| 6T6063 | 31 PINION-BEVEL (14-TEETH) | 1 | |
| 5P9066 | 32 RACE-BEARING OUTER | 1 | |
| 2K1738 | BEARING-INNER | 1 | |
| 5M4480 | 33 RING-RETAINING | 1 | |
| 0616711 | 34 RING-RETAINING | 1 | |
| 6T2805 | 35 GEAR (38-TEETH) | 1 | |
| 7G9228 | 36 SHIM PACK (INCLUDES 11-SHIMS) | 2 | |
| 2R0239 | 37 SEAL-O-RING | 1 | |
| 7G9270 | 38 CAGE-BEARING | 1 | |
| 0S1594 | 39 BOLT (3/8-16X1-IN) | 8 | |
| 1T0043 | 40 BALL BEARING | 1 | |
| 7T2636 | 41 ROLLER | 13 | |
| 1T0680 | 42 SPRING-FREEWHEEL | 13 | |
| 1T1466 | 43 CAM-FREEWHEEL | 1 | |
| 6V0320 | 44 RING-RETAINING | 1 | |
| 6V0321 | 45 RING-RETAINING | 2 | |
| 2P1005 | 46 BUSHING | 2 | |
| 1P6071 | 47 RACE-THRUST BEARING | 4 | |
| 1P6070 | BEARING-THRUST | 2 | |
| 7G5092 | 48 HUB | 1 | |
| 7G9246 | 49 HUB | 1 | |
| 6T9072 | 50 SHAFT AS | 1 | |
| 4B9784 | BALL | 1 | |
| 6T5664 | 51 GEAR (54-TEETH) | 1 | |
| 0S1594 | 52 BOLT (3/8-16X1-IN) | 8 | |
| 0S1587 | 53 BOLT (1/2-13X1.75-IN) | 10 | |
| 7G9237 | 54 RING-SEAL | 1 | |
| 7G9226 | 55 PLATE-LOCK | 2 | |
| 0S1608 | 56 BOLT (3/8-16X3.75-IN) | 6 | |
| 0T0065 | BOLT (3/8-16X3.5-IN) | 2 | |
| 8F8882 | 57 SEAL-O-RING | 2 | |
| 6T7235 | 58 PLATE | 1 | |
| 6T7238 | 59 PISTON | 1 | |
| 7D8225 | 60 SEAL-RING | 1 | |
| 6T7236 | 61 HUB-CLUTCH | 1 | |
| 6T7239 | 62 SPRING-DISC | 2 | |
| 7G9241 | 63 DRUM | 1 | |
| 7G9253 | 64 HUB | 1 | |
| 6Y8844 | 65 DISC-FRICTION | 5 | |
| 3P0337 | 66 PLATE-CLUTCH | 4 | |
| 7G9243 | 67 PLATE | 1 | |
| 2L0044 | 68 RING-SNAP | 1 | |
| 0S1594 | 69 BOLT (3/8-16X1-IN) | 25 | |
| 7G5099 | 70 COVER | 1 | |
| 1H8128 | 71 SEAL-O-RING | 1 | |
| 0S1588 | 72 BOLT (3/8-16X1.25-IN) | 2 | |
| 7G5098 | 73 WASHER-RETAINING | 1 | |
| 9S3581 | 74 CUP-BEARING | 2 | |
| 9S3582 | CONE-BEARING | 2 | |
| 7G5096 | 75 SLEEVE-SEAL RING | 1 | |
| 9F7378 | 76 RING-SEAL | 2 | |
| 7G9264 | 77 CAGE-BEARING | 1 | |
| 8J8879 | 78 SEAL-O-RING | 1 | |
| 7G9964 | 79 SHIM PACK (INCLUDES 12-SHIMS) | 2 | |
| 7G9226 | 80 PLATE-LOCK | 2 | |
| 7G9227 | 81 SHIM PACK (INCLUDES 12-SHIMS) | 2 | |
| 0S1608 | 82 BOLT (3/8-16X3.75-IN) | 6 | |
| 0T0065 | BOLT (3/8-16X3.5-IN) | 2 | |
| 6T7235 | 83 PLATE | 1 | |
| 7G9237 | 84 RING-SEAL | 1 | |
| 8F8882 | 85 SEAL-O-RING | 2 | |
| 6T7238 | 86 PISTON | 1 | |
| 7D8225 | 87 SEAL-RING | 1 | |
| 6T7239 | 88 SPRING-DISC | 2 | |
| 6T7236 | 89 HUB-CLUTCH | 1 | |
| 7G9253 | 90 HUB | 1 | |
| 6Y8844 | 91 DISC-FRICTION | 5 | |
| 3P0337 | 92 PLATE-CLUTCH | 4 | |
| 7G9243 | 93 PLATE | 1 | |
| 2L0044 | 94 RING-SNAP | 1 | |
| 0S1587 | 95 BOLT (1/2-13X1.75-IN) | 10 | |
| 7G9241 | 96 DRUM | 1 | |
| 1P6071 | 97 RACE-THRUST BEARING | 2 | |
| 1P6070 | BEARING-THRUST | 1 | |
| 2P1005 | 98 BUSHING | 2 | |
| 6T5664 | 99 GEAR (54-TEETH) | 1 | |
| 7G9245 | 100 HUB | 1 | |
| 1T0807 | 101 RACE-THRUST BEARING | 1 | |
| 0S1594 | 102 BOLT (3/8-16X1-IN) | 10 | |
| 5M2894 | 103 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 6T5327 | 104 CYLINDER AS | 1 | |
| 3J7168 | BEARING | 1 | |
| 7W0134 | 105 SPRING-PUMP | 1 | |
| 6T5325 | 106 PISTON | 1 | |
| 1P9252 | 107 RING-SEAL | 1 | |
| 1H9696 | 108 SEAL-O-RING | 1 | |
| 6T5995 | 109 PLATE | 1 | |
| 2M6301 | 110 RACE-BEARING OUTER | 3 | |
| 5M0704 | BEARING-INNER | 3 | |
| 9N4639 | 111 GEAR (12-TEETH) | 1 | |
| 6T5986 | 112 COUPLER | 1 | |
| 1B8709 | 113 KEY-WOODRUFF | 1 | |
| 6T5985 | 114 GEAR (65-TEETH) | 1 | |
| 7T7691 | 115 RETAINER AS | 3 | |
| 9M6803 | DOWEL | 2 | |
| 9W4332 | 116 SPRING | 3 | |
| 6T5987 | 117 SHAFT | 1 | |
| 2A0762 | 118 BOLT (1/4-20X0.625-IN) | 6 | |
| 8F8733 | 119 SEAL-O-RING | 2 | |
| 7T7674 | 120 SHIM PACK (INCLUDES 11-SHIMS) | 2 | |
| 7G9378 | 121 CAGE-BEARING | 1 | |
| 7T7689 | 122 BOSS | 1 | |
| 6Y0326 | 123 FORK AS | 1 | |
| 1L8631 | BUSHING-GUIDE | 2 | |
| 4B4845 | 124 PLUG | 2 | |
| 7T6555 | 125 SPRING | 1 | |
| 6Y0324 | 126 SHAFT | 1 | |
| 5H6005 | 127 SEAL-O-RING | 1 | |
| 5F8000 | 128 SEAL-O-RING | 1 | |
| 6T8576 | 129 SHIM PACK | 2 | |
| 6Y0327 | 130 COVER | 1 | |
| 9G9606 | 131 GEAR (22-TEETH) | 1 | |
| 6B1557 | 132 BOLT (3/8-16X7.5-IN) | 1 | |
| 9G9607 | 133 CAGE-BEARING | 1 | |
| 0S1619 | 134 BOLT (3/8-16X3-IN) | 1 | |
| 3S4388 | 135 WASHER-RETAINING (10.31X63.5X8.64-MM THK) | 1 | |
| 4D3478 | 136 SPACER | 1 | |
| 1A1415 | 137 NUT (1-7/8-12-THD) | 2 | |
| 1A5954 | 138 WASHER | 2 | |
| 2H3927 | 139 SEAL-O-RING | 2 | |
| 7G9379 | 140 FLANGE | 1 | |
| 1J2176 | 141 SEAL-O-RING | 1 | |
| 7G9239 | 142 SHIM PACK (INCLUDES 7-SHIMS) | 2 | |
| 9G5657 | 143 SHAFT AS | 1 | |
| 4B9783 | BALL | 1 | |
| 0S1594 | 144 BOLT (3/8-16X1-IN) | 14 | |
| 1D4616 | 145 BOLT (3/4-10X6-IN) | 9 | |
| 7G9238 | 146 RING-RETAINING | 1 | |
| 7D8637 | 147 CUP-BEARING | 2 | |
| 7D8636 | 148 CONE-BEARING | 2 | |
| 7G9268 | 149 GEAR (41 TEETH) | 1 | |
| 1S8385 | 150 RING-RETAINING | 1 | |
| 7G9230 | 151 RING | 1 | |
| 6V7352 | 152 SEAL-LIP TYPE | 1 | |
| 2K2939 | 153 SEAL-O-RING | 1 | |
| 7G9249 | 154 RETAINER-SEAL | 1 | |
| 5P0713 | 155 SEAL-LIP TYPE | 1 | |
| 7G9225 | 156 SPACER | 1 | |
| 2P8986 | 157 CUP-BEARING | 2 | |
| 2P8987 | CONE-BEARING | 2 | |
| 9P2214 | 158 CLAMP-CABLE | 1 | |
| 0L1351 | 159 BOLT (3/8-16X0.875-IN) | 1 | |
| 5P2568 | 160 SEAL-O-RING | 1 | |
| 6Y2688 | 161 DRUM AS | 1 | |
| 6F4161 | DOWEL | 1 | |
| 6P9546 | 162 PLUG | 1 | |
| 9P2756 | 163 SPACER | 1 | |
| 6P9547 | 164 SPRING | 1 | |
| 6P9548 | 165 KNOB | 1 | |
| 7M7260 | 166 GASKET-LIQUID (8-OZ CAN) |
